Product Description
Quasar 924-5223 2' 2-Bank Shell C/W Ossium Plate & 2x 2' Rainbow 2
Top Product Highlights
- Control shape and spill with articulated Shell
- Secure tubes quickly into a bank using Ossium Plate
- Ossium Baby Pin included for rigging
- Includes Rainbow 2 tubes
- High quality tunable white light and high RGB color saturation
- Bank of individually addressable pixels
- Direct connect every industry standard wired and wireless control option
OVERVIEW
SEE THE BIGGER PICTURE
Shape a bigger image with a bank of pixelated Rainbows lights encased in an ultra-flexible shell. The Rainbow Ossium Shells supersize RGBX pixel control in a format that’s mercifully simple to rig and manipulate on set.
PAINT WITH LIGHT ON THE BROADEST CANVAS
Banking Rainbows creates a larger canvas to paint with. Up to 4ft wide and conveniently low-profile, an Ossium Shell brings Hollywood lighting without the demands for extra space or fuss.
Paint your world with intense white light or deeply saturated color. Or light with an image using individual pixel mapping. The sky’s not the limit it’s an option.
A SMARTER WAY TO STACK AND CONTROL
Solid support from a custom Ossium plate keeps your Rainbows straight and true – this is the last place you want flexibility. Stacking them into a larger array is simple using the integrated Ossium Rail and quick connect power via the included multibank AC adaptor (it’s all doubly quick with Double Rainbows).
There’s no separate ballast to eat up rigging time. Smaller Shells come with an Ossium Baby Pin and the Super G Multi Axis Mounting System is included with the large 4ft 4-banks to give maximum control over tilt, pan and rotate.
CONTROL THE RAINBOW, SHAPE THE WORLD
Take control of your source with the flexible Shell. Color is unbounded but sometimes the light needs to have limits.
The Shell gives control over shape and spill using articulating doors, holding any position you choose. For even more direction add an optional 40° Eggcrate.
THE POWER OF MANY ACTING AS ONE
Light the way you want with a large, pixel-mapped array that has an alter ego as individual tubes. The Rainbows offer high quality tunable white light and the highest color saturation with multiple pixels maintaining super smooth, flicker free dimming.
Direct connect every industry standard wired and wireless control option from DMX and Bluetooth through to sACN. Is the multibank shell a huge creative canvas or a tool for your tubes? We guess that depends on where the day takes you.
A SLEEK SHAPE PROVIDES A POWERFUL LIGHT SOURCE USING LITTLE SPACE.
From lighting actors to environments, high quality tunable white light and the highest RGB color saturation with multiple pixels maintaining super smooth, flicker free dimming, the R2 will be your workhorse. This linear LED light offers incredible data connectivity whether wired or wireless and can be powered anywhere via AC and DC power inputs. Integrated Ossium Mounting System (OMS) allows for rigging in ways previously unobtainable.
COLOR SCIENCE
CONNECTIVITY
MOUNTING
Ossium Mounting System (OMS) integrates seamlessly and efficiently with industry standard hardware for safer, faster rigging with greater precision and style.
PIXELATION
With more pixels and greater control than any other tube lights, Rainbow fixtures produce more realistic animation to take your lighting effects to a whole new realm. More than just volume, spectrally-based color calibration provides each pixel with dependable vibrant color values.
OUTPUT
Vibrant saturated colors and the most intense white light, deliver great results in any situation.
POWER ANYWHERE
Power R2 lights anywhere with plug and play AC and DC capabilities. Direct AC input without power supply, or The Ossium Battery Plate making swapping batteries seamless reducing down time on set.
UNIVERSAL AC & DC POWER INPUTS
The R2 can be powered through either the universal AC power input for mains power anywhere or the auxiliary DC input for use with power bricks and battery packs.
EXPANDED ONBOARD FX ENGINE
The R2 is enabled with generous FX presets with a multitude of new parameter controls allowing you to fine tune everything from Emergency to Paparazzi. Adjust Hi/Low Intensities, Speed, Color and more.
IN THE BOX
- (2x) Rainbow 2 Linear LED Light - 2'
- (1x) 2' 2-Bank Polyshell c/w dual plate
- (1x) Ossium Baby Pin
- (1x) Multibank Power Adaptor, 2-Bank
SPECIFICATIONS
Wattage | 25 W |
---|---|
Stock Lens System | 180º Diffused Lens |
AC Input | TRUE1 Connector |
AC Voltage: |
120-240 V |
DC Input | 4-Pin Push-Pull to PTAP Connector |
DC Voltage | 12-30 V |
Internal Battery | N/A |
Control Interface | OnScreen OLED with Manual Controls |
Wired Control Protocols | DMX, Art-Net, sACN |
Wireless Control | Wireless DMX (CRMX), Bluetooth, WiFi |
Dimming | 0-100% Continuous Onboard, 3 Output Levels |
Color System | RGBX Spectral Science Color Engine |
Luminous Output | 1266 lumens |
Incident Illumination | @ 10'/3m: 5600K: 42.3 lux / 4.06 FC |
CCT Range | 1,750K - 10,000K |
Maximum Spectral Fidelity | 2250K: SSI[P2250] 91 / 3200K: SSI[P3200] 83 / 5600K: SSI[CIE D5600] 74 |
Color Rendition | 2000K TM-30 Rf: 94 / 3200K TM-30 Rf: 93 / 5600K TM-30 Rf: 94 |
IP Rating | IP40 |
Certifications | ETL, cETL, FCC |
Mounting | Ossium Mounting System, T12 Mounting & Q-Blocks |
LED Lifetime | 25,000 Hours |
DIMENSIONS
Length | 720 mm | 28.3 in |
---|---|---|
Width | 240 mm | 9.4 in |
Depth | 220 mm | 8.7 in |
Weight | 4.65 kg | 10.3 lbs |
