Product Description
Martin Lighting ERA 150 Wash Moving-Head LED Wash Fixture with Zoom
Overview
The Martin ERA 150 Wash moving-head LED wash fixture provides class-leading lumen output, high-intensity narrow zoom and full-gamut color calibration for accurate color reproduction and color temperature control, making it an incredibly versatile yet affordable workhorse lighting solution for rentals, installs and touring.
The ERA 150 Wash takes performance even further thanks to a newly designed optical system that produces a wider zoom range, higher output and wide uniform wash field. Other advancements include advanced color-calibration features including extended color mode and a CTC channel that allows RGB color mixing around your desired white point.
Whether lighting a theatre production, live concert, exhibition or corporate event, fill the stage with color and create brilliant, focused beam effects with this flexible moving-head fixture that brings new versatility to the designers' toolbox.
Class-Leading Lumen Output
The ERA 150 Wash delivers a stunning 3,900 lumens—twice the brightness of the previous generation of compact wash moving heads—thanks to its newly designed 7 x 40W RGBW light engine. This superior output covers larger stages that require longer throw distances.
High-Intensity Narrow Zoom for Versatile Effects
The ERA 150 Wash's newly designed zoom system can produce precise beam angles as narrow as 4 degrees, delivering a high intensity of over 370,000 cd. It's perfect for creating sharp, punchy mid-air beams, cutting through light levels previously not possible in a wash fixture of its size.
Full-Gamut Color Calibration
The ERA 150 Wash features a full-gamut color calibration system, which allows consistent color reproduction from fixture to fixture and supports a dedicated color temperature control channel for adjusting the color space from the desired color temperature.
Ultra-Quiet Operation
In Theatre mode, the ERA 150 Wash operates at 33 dB-literally as soft as a whisper.
Tour Ready
The ERA 150 Wash is housed in a lightweight yet durable chassis, and offers a USB firmware update system and battery backup display.
Features
- Light engine: LED 7 x 40W RGBW
- Full-gamut color calibration
- CTC control: 1,800–12,850 K
- High output: 3,700 lm
- High intensity 397,783 cd
- Zoom: 4.2 - 58˚
- Low-noise cooling system
- High-speed pan, tilt & zoom
- Weight 7.3 kg (16.1 lbs.)
- Dimensions: 276 x 176 x 356 mm (10.9 x 7.0 x 14.1 in.)
Specifications
*Figure obtained under manufacturer's test conditions
* All Photometric Data measured in steady state (30 minutes warm-up time) at 25°C ambient.
AC power: 100-240 V AC nominal, 50/60 Hz
Power supply unit: Auto-ranging electronic switch mode
Typical half-cycle RMS inrush current at 240 V, 50 Hz: 8.7 A
Power Factor: 0.99 @ 100 V / 120 V , 0.97 @ 220 V / 230 V / 240 V
Typical current draw: 3.8 A @ 100 V / 120 V , 1.5 A @ 220 V / 230 V / 240 V *
Power Consumption
Typical: 315 W *
* Measurements made at nominal voltage. Allow for a deviation of +/- 10%.
Typical: full output white, no effects moving, regulated fan speed.
*Calculated, +/- 10%, at full intensity, full white
LWR = Lumen-to-Weight Ratio
