Product Description
Leviton TS007 Sapphire, Touch Screen, Dimmer Switch, Room Controller, LED Controller, Lighting Control
Sapphire™ 7” Touch Screen, Capacitive Interface, No Faceplate Included. NOTE: Control interface only. Requires load control device for dimming and/or switching.
Faceplate is available in white, light almond, and black, and is sold separately.
The Sapphire™ Touch Room Controller Dimmer Switch provides the flexibility of a fully customizable user interface with the convenience of native controls from Leviton Commercial System products. Integrate room controls, including, dimming, occupancy/ vacancy sensing, partial-ON and partial-OFF from one elegant interface. The Leviton Sapphire Room Controller is a premier touch screen offering occupancy/photocell sensing, full-range automatic dimming, color tuning and daylighting integration. The scheduler feature allows facility and building managers to schedule holidays and daily lighting schedules from the touch screen.
|
PRODUCT FEATURES
|
|
| Product Line | Sapphire LCD Touch Screen |
| Product Type | Touch Screen Lighting Control, Dimmer Switch, Room Controller, LED Controller |
| Protocol | LumaCAN |
Features & Benefits:
- 7” Capacitive Touch Screen
- User Interface Components: Tabs/Pages, Buttons, Sliders
- Touch screen status updated from actual device status
- LumaCAN® Connectivity
- Secure Password Protected Administration
- Online/Offline configuration and screen design through PC Tool
- Software & Configuration updates through front panel USB memory stick
- Available Faceplates: White, Light Almond, Black
Description Sapphire™ Room Controller provides the flexibility of a fully customizable user interface with the convenience of native controls from Leviton’s Commercial Systems products. Integrate room controls, including occupancy/ vacancy sensing, partial-ON and partial-OFF from one elegant interface. Sapphire Room Control is Leviton’s premier touch screen offering occupancy/photocell sensing, full-range automatic dimming, color tuning and daylighting integration. The scheduler feature allows facility and building managers to schedule holidays and daily lighting schedules from the touch screen.
Applications • Color tuning—0-10V, DMX (requires interface hardware) • Conference room control • Building supervisor control panel • Classroom control • Executive office control • Ballroom control • Anywhere touch-interface is desired
Features • 7” capacitive LCD touch screen • Supports Sapphire User Interface (UI) components and commands • Supports Sapphire Scheduler • Supports Sapphire Room Controls • LumaCAN and analog input connectivity • Analog input supports photocell, occupancy, and momentary/maintained switch • Secure password protection administration access • Offline UI configuration through Sapphire Studio PC Tool • All software is updated through a front-panel USB memory stick • Available faceplates—White, Light Almond, & Black
Sapphire User Interface Components & Commands • All UI elements are updated from live network status • Uses tabs for organization of UI elements into pages • Each tab has a custom name • Each tab can offer secured access with a PIN • Buttons • Button operating modes • Toggle • Press/release • Preset group • Configurable caption • All network commands supported • Sliders • Configurable caption • Supports only set channel/group level commands • Configurable numeric level display • Network Commands • Administrative functions • Network setup • Log file import/export • Configuration update • Snapshot record • Snapshot edit • Set channel and group level • Fade stop • Fade rate or fade time • Raise/lower
