Johnson Systems PM-2L-DE Dual 600 Watt LED Dimmer Module for Strand Digital Environ Racks
Overview
120VAC LED Dimmers for Strand CD80® Supervisor and C21 Dimmer Racks. Employing next-generation MOSFET power devices, these Dimmer Modules are designed for direct plug into any dual 2.4KW rack slots. These modules provide a fast conversion to state-of-the-art LED dimming boasting dimming efficiency of ≥99%. Leveraging the same intelligent control circuitry as used in the Presidor™ LED Dimmer Racks, these modules are controlled with our CD-3000+ processors for state-of-the-art dimming.
Each dimmer module contains two isolated, reverse phase controlled dimmers rated at 600 Watts and will dim both LED and incandescent loads over a full range of dimming (1-100% DMX). Unique digital curve selection allows for user selectable low end curve setting. Sensing protection on each dimmer includes overload, short-circuit, temperature, over-voltage, inductive load and more. RGB LED indication permits fast diagnosis of any load error events.
Features
- Each module contains two 600 Watt reverse phase dimmers.
- Chokeless MOSFET power outputs for unsurpassed dimming efficiency (≥99%).
- Designed for use with CD-3000+ rack processors only!
- Dims both LED and Incandescent loads from 1-100% DMX.
- Intelligent load sensing.
- Instant software load shut-off for short-circuit, overload, over-temp, inductive load, and more.
- Ultra-low standby power for "Green" compliancy.
- RGB LED feedback for fast diagnosis of load.
- ETL compliant module & UL489 10 Amp Breaker.
