Product Description
Iluminarc LOGICDRIVE2X LOGIC Drive 2X
Overview
The Logic Drive 2X is designed to feed power and control to remote fixtures using the POE latest standard IEEE 802.3 bt (power over Ethernet) and TCP/IP for control. It has 2 output ports and will support a maximum of 92.5 W/port. The Drive 2X includes one LOGIC Wall Con, which is a single gang wall controller that can recall up to 8 recorded scenes from the Drive 2X. Additional Wall Cons may be added to the system, up to 4 pcs on a single controller to have multiple control locations. The Drive 2X supports DMX, Art-Net, and sACN control protocols, and includes an integrated webserver to configure the date/time settings, which are used in the daily/calendar trigger.
Features
- 2 POE (Power Over Ethernet) outputs, each supplying up to 110W
- Control options include standard wall controllers, or DMX input via 5-pin XLR, Art-Net, or sACN
- Occupancy sensor-enabled
- Supports fixture hot-swapping and automatic fixture detection
- Current and voltage monitoring
- RDM compliant
