Product Description
Electro-Voice EVU-2062/95 Dual 6.5" Two-Way 90 x 50 Full-Range Loudspeaker System
Overview
The EVU-2062/95 Dual 6.5" Two-Way 90 x 50 Full-Range Loudspeaker System from Electro-Voice is a compact loudspeaker system that can be used in a variety of applications where high quality sound reinforcement is required in an ultra-compact lightweight enclosure. The enclosure design utilizes asymmetric angles to maintain tight clearances to walls and ceilings while providing optimal coverage patterns. This design was optimized for wall, stage lip and under balcony applications.
The system incorporates the ICT-1-8, a high-output 1.3” diaphragm titanium compression driver coupled to a Constant Directivity 90 x 50° rotatable waveguide. The ICT-6.5-16 woofer is developed using FEA optimization to provide the high sensitivity while achieving the maximum level of speech intelligibility. The crossover design uses 18-dB-per-octave slopes with equalization for very smooth response in the vocal range, linear off-axis response and a protection circuit for long term reliability.
The EVU series is constructed of 9-ply hardwood plywood enclosures with six integral M8 suspension points to support a wide variety of mounting positions. The EVU system is finished in textured paint, available in either white or black. Each EVU system includes a universal U-bracket to facilitate mounting. The U-bracket provides full 330° unobstructed rotation of the loudspeaker if the transformer kit (not included) is installed.
Features
- 1.3” Diaphragm, 1.4” exit pure titanium compression driver
- 6.5” LF transducer
- Advanced third-order crossover network with HF protection
- Coverage pattern 90 x 50° constant directivity rotatable waveguide
- 94 dB sensitivity, 125 dB maximum SPL
- System rating 300 W continuous, 1200 W peak
- Universal U-bracket included
- Six M8 threaded suspension points
Specifications
Enclosure Type | |
Total Power Capacity | |
System Impedance |
HF Driver | |
MF Driver | |
LF Driver |
Frequency Range | |
Frequency Response | |
Maximum SPL | |
Coverage Angle | |
Speaker Sensitivity | |
Protections |
Audio I/O |
Crossover | |
Phase Adjustment |
Mounting | |
Handles | |
Construction Material | |
Dimensions | |
Weight |
