Product Description
Elation Proteus Maximus IP65 950W LED Profile
The PROTEUS MAXIMUS an extremely bright IP65 rated LED Profile fixture offering outstanding projection, beam and wash qualities in any environment.
Providing up to 50.000 lumens from its custom designed 950W 6,500K LED engine the Proteus Maximus is the ideal fixture for any outdoor application requiring superior output, bright and powerful beams, quiet operation as well as stunningly precise gobos and colors. Proteus Maximus provides the designer a comprehensive FX package with 6 rotating and 7 fixed glass gobos, full animation wheel, dual prisms, dual frost and a high-speed Iris. Its indexable framing system provides full blackout shutter cuts for precise beam shape control.
With a fast zoom range from 5.5° to 55° and an impressive 180mm front lens the Proteus Maximus has the power to cut through at great distances in any outdoor concert, special events and with its fully dust and water proof design it is an ideal fixture for theme parks and cruise ships.
The PROTEUS MAXIMUS fixture ships in a cardboard box with a custom fitted polyurethane foam FIL (Foam In Lay) insert. This foam insert easily fits into a custom sized flight case (not included), and provides enhanced impact protection during transport.
Features
- High Efficiency 950W 6,500K White LED Engine
- Up to 50.000 Total Lumen Fixture Output
- CMY Color Mixing and Variable CTO
- 6 Position Color Wheel, High CRI, UV filter
- Complete FX System featuring Rotating and Fixed Gobos, Animation, Iris, Dual Prism, Dual Frost
- Indexable Full Blackout Framing System
- Wide Zoom Range from 5.5° to 55° / Large 180mm Front Aperture
- FIL (Foam In Lay) Polyurethane Foam Packaging Included
Specifications
SOURCE
- 950W 6,500K Bright White LED Engine
- 30,000 Hour Average LED Life*
*May vary depending on several factors including but not limited to:
Environmental Conditions, Power/Voltage, Usage Patterns (On-Off Cycling), Control, and Dimming.
PHOTOMETRIC DATA
- 50,000 Total Lumen Output
- CRI 70+ (82+ with HCRI Filter)
- 2:1 Hotspot Ratio
- Zoom Range 5.5° - 55°
- Beam Angle 4.8° - 41.2°
- Field Angle 6.1° - 51°
EFFECTS
- Motorized Zoom (Large 180mm Front Aperture)
- 4 Rotating Full Blackout Framing Blades
- +/-45° Framing Indexing
- Full 360° Bi-Directional Animation Wheel
- 4-Facet and Linear Rotating Prisms
- 2 Variable Frost Filters (Light and Wash)
- Internal Color, Framing, Prism, and Frost Macros
- Motorized Iris with Variable Pulse Effects
- Variable 16-bit Dimming Curve Modes
- High Speed Electronic Shutter and Strobe
- DMX Controllable LED Refresh Rate
COLOR
- CMY Color Mixing
- Linear CTO Color Correction
- 6 Dichroic Colors including High CRI Filter and UV
GOBOS
- 2 Gobo Wheels
- 6 Rotating / Indexing Interchangeable Glass Gobos
- 7 Static Glass Gobos
CONTROL / CONNECTIONS
- 2 DMX Channel Modes (37 / 61)
- 16-bit Pan, Tilt and Dimming Control
- Motorized Focus and Auto-Focus Presets
- DMX, RDM, Art-NET, sACN Protocol Support
- (6) Button Touch Control Panel
- Full Color 180° Reversible LCD Menu Display
- Hibernation Mode (Power Save)
- 5pin XLR DMX In/Out
- IP65 RJ45 ethernet In/Out
- IP65 Locking Power Cable In
- With Wired Digital Communication Network
SIZE / WEIGHT
- Length: 18.0 in (458mm)
- Width: 23.3 in (591mm)
- Height: 32.5 in (825mm)
- Weight: 117 lbs. (53kg)
ELECTRICAL
- AC 120-240V 50/60Hz
- Max Power Consumption 1,400W
- 14°F to 113°F (-10°C to 45°C)
APPROVALS / RATINGS
- CE | cETLus | IP65
