Product Description
Elation Fuze Profile 305W RGBMA LED Profile Moving Head
The FUZE PROFILE is an automated LED framing fixture designed for theater, television and a wide array of other precision lighting applications. The 92 CRI engine utilizes a 5-color homogenized LED array consisting of Red, Green, Blue, Mint, and Amber sources. The carefully tuned LEDs ensure accurate color reproduction while delivering a powerful output of over 10,000 lumens. Virtual color temperature, Magenta / Green adjustment plus CMY emulation provide the designer with immediate access to the impressive LED color array.
The FUZE PROFILE is designed for any application where fully automated ellipsoidal fixture with outstanding and impactful color range and quality is required. A rotating gobo wheel, fixed gobo wheel, animation wheel, frost, prism and iris round out its comprehensive feature set in a compact, quiet and lightweight fixture.
Features
- Extended color RGBMA LED Engine, 92 CRI
- Rotating and Fixed Gobos plus Animation Wheel
- Full Blackout Framing System
- Iris, Prism, and Frost
- Wide Zoom Range from 7° to 42°
Specifications
SOURCE
- 305W 6,500K RGBMA LED Engine
- 30,000 Hour Average LED Life*
PHOTOMETRIC DATA
- 10,100 Total Lumen Output
- CRI 92
- Zoom Range 7° - 42°
- Beam Angle 7.5° - 39.9°
- Field Angle 8.6° - 44.2°
EFFECTS
- Motorized Zoom
- 4 Rotating Full Blackout Framing Blades, +/- 60 Index
- Variable Frost Filter
- 4 Facet Prism
- Motorized Iris
- Variable 16-bit Dimming Curve Modes
- High Speed Electronic Shutter and Strobe
COLOR
- RGBMA Color Array
- CMY Emulation
- Virtual Color Correction
- Green/Magenta Shift
- Virtual Gel Swatch Book
GOBOS
- 1x 6 Rotating / Indexing Interchangeable Glass Gobos
- 1x 7 Fixed Glass Gobo
- Animation Wheel
CONTROL / CONNECTIONS
- 4 DMX Channel Modes (RGBMA 38 / 59) (CMY 36 / 55)
- 16-bit Pan, Tilt, and Dimming Control
- DMX Adjustable LED Frequency
- DMX, RDM Protocol Support
- 4 Button Touch Control Panel
- Full Color 180° Reversible LCD Menu Display
- 16 Bit Resolution Adjustable Movement
- 5pin DMX In/Out
- IP65 Locking Power Cable In/Out
- With Wired Digital Communication Network
SIZE / WEIGHT
- Length: 16.0” (407mm)
- Width: 10.1" (256mm)
- Vertical Height: 27.4" (698mm)
- Weight: 55.1 lbs. (25kg)
ELECTRICAL / THERMAL
- AC 100-240V - 50/60Hz
- 540W Max Power Consumption
- 14°F to 113°F (-10°C to 45°C)
- BTU/hr (+/- 10%) 1841
APPROVALS / RATINGS
- CE | cETLus | IP30
FIRMWARE UPDATES
- Current Version: V1.09
