More Flexibility
• True Ethernet backbone – fast, reliable and scalable
• Color LCD provides users with diagnostics and presets for easy setup
• Includes SLM (Sweep Load Monitoring) with system-level diagnostics
• Front panel USB connector transfers presets to/from a USB drive to the amp’s DSP
• New software interface based on customer feedback manages presets, provides easier system-level changes, and includes a configuration wizard
• The only product available with analog, AES, CobraNet®, HiQnet™ and Ethernet connectivity
No Compromise
• BSS OMNIDRIVEHD™ DSP processing with industry leading IIR filters and linear phase FIR filters
• High common-mode rejection eliminates hum and RFI on input cables
• Professional-grade connectors for all inputs and outputs
• Full power-supply voltage is always available, allowing instantaneous power on demand
• Quality-graded components let you safely drive the amplifier harder
• More total capacitance provides tremendous energy reserves for power bursts
No Comparison
• The only tour sound amplifier that provides four routable inputs to any output (analog, AES, VDrive, or CobraNet)
• LevelMAX™ peak voltage and RMS power limiters communicate with each other, resulting in smooth and accurate response, better sound
• Sixth generation patented Class-I (BCA®) circuitry couples power efficiently to the load and provides low AC current draw
• Global Power Supply; universal AC input accepts 100-240VAC, 50/60 Hz (±15%)
Specifications
Channels | 4 inputs, 4 outputs (Analog, AES 3, VDrive, CobraNet) |
Sensitivity | Adjustable in 0.1dB increments from 1.28Vrms to 8Vrms |
Damping Factor | >5000 |
Signal to Noise Ratio | ≥108dB |
THD (full rated power, 20 Hz - 20 kHz) | 0.35% |
Frequency Response | ±0.25dB |
Intermodulation Distortion (from 0 dB down to -40 dB) | 0.06% |
Crosstalk | >80dB |
Common Mode Rejection | >80dB typical |
Power Connector | 32A PowerCON |
Dimension (HxWxD) | 89mm x 483mm x 431mm 3.5in x 19in x 16.9in |
Net Weight | 13.2kg (29lbs) |
