Product Description
Allen & Heath AH-IP-4 Four Button IP Control, PoE Powered, Decora Style
Overview
The KP-4 keypad enhances any RTI control system, providing fast, convenient control of music, lights, shades, and more. Its four fully programmable buttons offer intuitive two-way feedback with configurable backlight colors.
It includes white keypad faceplates with matching keycaps. For a personalized touch, RTI’s Laser Shark™ engraving service allows custom text and graphics on keycaps, available in White.
Designed for seamless integration, the KP-4 fits standard Decora® wall plates and single-gang US electrical boxes, ensuring a clean, intuitive control solution for residential and commercial spaces.
Powered via PoE, the KP-4 uses a single network cable for both power and communication with the RTI processor, simplifying installation.
Features
- Four programmable buttons
- Free Laser Shark engraving for one keycap set
- PoE for control, communication, and power
- Includes white keypad faceplates with label kits
- Individually programmable button backlight (16 colors)
- Fully customizable and programmable
- Fits standard single-gang electrical boxes
- Supports network or USB programming
- Compatible with standard Decora® wallplates (not included)
Specifications
- Power: PoE IEEE 802.3af
- Backlights: RGB LED, 16 programmable colors
- Control Port: 10/100 Base-T with PoE
- Memory: 512KB Flash (non-volatile)
- Macro Support: Programmable macros on all buttons
- Programming: USB Type-C port
- Enclosure: Black powder-coated steel
- Front Plate: High-impact molded ABS plastic (white)
- Mounting: Standard US single-gang box
- Front Plate Dimensions (H x W): 4.6” x 2.75” (117 mm x 70 mm)
- Unit Dimensions (H x W x D): 4.1" x 1.8" x 1.7" (104 mm x 46 mm x 43 mm)
- Installation Cut-Out (H x W): 2.8" x 1.8" (71 mm x 46 mm)
- Depth in Wall: 1.37" (34 mm) plus cables
- Operating Temp: +32°F to +122°F (0°C to +50°C)
- Humidity: 5% to 95% non-condensing
- Weight: 4 oz (113 g)
- Warranty: Three years (parts & labor)
- Accessories: Compatible with Decora® wallplates (sold separately)
