ADJ LP 42 RGBW Eliminator Lighting LP 42 RGBW LED Par
Overview
Lighting designers and mobile DJs in search of an affordable wash light will appreciate the Eliminator Lighting LP 42 RGBW, a lightweight LED par with forty-two 1W LEDs (12 red, 12 green, 12 blue, and 6 white LEDs) and a 25-degree beam angle. Made from durable plastic with a metal scissor yoke, the LP 42 can be used for permanent or portable installations, on small stages, in lounges, bars, or fun centers, or for events, mobile DJing, and more.
The LP 42 RGBW is built with a Sound Active mode or can be connected with DMX cables to use the built-in programs and linkable features. It is equipped with 3-pin DMX in/out, as well as an IEC in/out connection to daisy-chain the power from one fixture to another. Additionally, a 4-button function menu with an LED display is available to help you navigate through the various features.
Features
- LEDs: 42 x 1W LEDs (12 red, 12 green, 12 blue, and 6 white LEDs)
- Beam Angle:25°
- Lux: 3600 at 6.6'
- DMX Channels: 4 or 8; selectable
- Static color, color change, fade, auto, sound active, and master/slave modes
- 0 to 100% dimming and variable strobe
- 4-button function menu with LED display
- Scissor yoke included, which allows for multiple rigging or floor/standing applications
- 3-pin DMX in/out
- IEC in/out connections to daisy-chain power
- Fan cooled
Specifications
Light
Fixture Type |
PAR |
Light Source |
42 x Color LED - 1 W |
Colors |
1 x Red 1 x Green 1 x Blue 1 x White |
Photometrics |
334.4 fc / 3600 Lux at 6.6' / 2 m |
Shutter / Strobe |
Electronic |
Dimming |
Electronic, 0 to 100% |
Performance
Operating Modes |
Automatic, Color Change, DMX, Master/Slave, Sound-Active |
Macros / Programs |
Auto-Program |
Effects |
Strobe |
Gobos |
None |
Control
Control Protocols |
DMX512 |
DMX Channel Modes |
3 Mode(s): 4 / 6 / 8-Channel |
Display / Controls |
LED / 4-Button |
Remote Control |
None |
Connectivity
Inputs/Outputs |
1 x XLR 3-Pin DMX Input 1 x XLR 3-Pin DMX Output |
Power
AC Input Power |
100 to 240 VAC, 50/60 Hz |
AC Power Connector |
Input: 1 x IEC Output: 1 x IEC |
Fuse |
F 5 A 250 V |
Power / Current Consumption |
56 W |
Physical
Mounting |
Mounting Bracket |
Exterior Color |
Black |
Dimensions |
10.51 x 10.47 x 2.87" / 26.7 x 26.59 x 7.29 cm |
Weight |
2.2 lb / 1 kg |
Other Details
A. ADJ Products, LLC hereby warrants, to the original purchaser, ADJ Products, LLC products to be free of manufacturing defects in material and workmanship for a prescribed period from the date of purchase (see specific warranty period on reverse). This warranty shall be valid only if the product is purchased within the United States of America, including possessions and territories. It is the owner’s responsibility to establish the date and place of purchase by acceptable evidence, at the time service is sought.
B. For warranty service you must obtain a Return Authorization number (RA#) before sending back the product–please contact ADJ Products, LLC Service Department at 800-322-6337. Send the product only to the ADJ Products, LLC factory. All shipping charges must be pre-paid. If the requested repairs or service (including parts replacement) are within the terms of this warranty, ADJ Products, LLC will pay return shipping charges only to a designated point within the United States. If the entire instrument is sent, it must be shipped in it’s original package. No accessories should be shipped with the product. If any accessories are shipped with the product, ADJ Products, LLC shall have no liability whatsoever for loss of or damage to any such accessories, nor for the safe return thereof.
C. This warranty is void if the serial number has been altered or removed; if the product is modified in any manner which ADJ Products, LLC concludes, after inspection, affects the reliability of the product; if the product has been repaired or serviced by anyone other than the ADJ Products, LLC factory unless prior written authorization was issued to purchaser by ADJ Products, LLC; if the product is damaged because not properly maintained as set forth in the instruction manual.
D.This is not a service contract, and this warranty does not include maintenance, cleaning or periodic check up. During the period specified above, ADJ Products, LLC will replace defective parts at its expense with new or refurbished parts, and will absorb all expenses for warranty service and repair labor by reason of defects in material or workmanship. The sole responsibility of ADJ Products, LLC under this warranty shall be limited to the repair of the product, or replacement thereof, including parts, at the sole discretion of ADJ Products, LLC. All products covered by this warranty were manufactured after August 15, 2012, and bear identifying marks to that effect.
E.ADJ Products, LLC reserves the right to make changes in design and/or improvements upon its products without any obligation to include these changes in any products theretofore manufactured. No warranty, whether expressed or implied, is given or made with respect to any accessory supplied with products described above. Except to the extent prohibited by applicable law, all implied warranties made by ADJ Products, LLC in connection with this product, including warranties of merchantability or fitness, are limited in duration to the warranty period set forth above. And no warranties, whether expressed or implied, including warranties of merchantability or fitness, shall apply to this product after said period has expired. The consumer’s and/or Dealer’s sole remedy shall be such repair or replacement as is expressly provided above; and under no circumstances shall ADJ Products, LLC be liable for any loss or damage, direct or consequential, arising out of the use of, or inability to use, this product.
This warranty is the only written warranty applicable to ADJ Products, LLC and American Audio products and supersedes all prior warranties and written descriptions of warranty terms and conditions heretofore published.
MANUFACTURER’S LIMITED WARRANTY PERIODS:
Non L.E.D. Lighting Products = 1-year (365 days) Limited Warranty (Such as: Special Effect Lighting, Intelligent Lighting, UV lighting, Strobes, Fog Machines, Bubble Machines, Mirror Balls, Par Cans, Trussing, Lighting Stands etc. excluding LED and lamps)
Laser Products = 1 Year (365 Days) Limited Warranty (excluding laser diodes which have a 6 month limited warranty)
L.E.D. Products = 2-year (730 days) Limited Warranty (excluding batteries which have a 180 day limited warranty). Note: 2 Year Warranty only applies to purchases within the United States.
StarTec Series = 1 Year Limited Warranty (excluding batteries which have a 180 day limited warranty).
ADJ DMX Controllers = 2 Year (730 Days) Limited Warranty
All American Audio branded products = 1-year (365 days) Limited Warranty (except V-Plus Series Amplifiers)
All American Audio V-Plus Series Amplifiers = 3-year (1095 days) Limited Warranty
