Product Description
Toa YW-7000 G Antenna Booster for S4.16 & S5 Series
Overview
The YW-7000 is an antenna booster designed for use to compensate for high frequency loss (cable loss) that occurs when the antenna cable is extended. It is used in combination with the optional YW-7520 or YW-7570 Wireless Antenna. Since power is supplied from the antenna input terminal of the wireless tuner, the YW-7000 operates by simply connecting the antenna cable to it.
Specifications
Power Source
7 - 12 V DC
Current Consumption
35 mA
Frequency Range
606 - 638 MHz (G band)
Antenna Gain
Approx. 10 dB
Operating Temperature
–10 °C to +50 °C (14 °F to 122 °F)
Weight
50 g (0.11 lb)
Included Accessories
BNC cable (50 cm (1.64 ft) x
