Product Description
TOA VX-300LO Line Output Module
The VX-300LO provides a line level audio output and can be used instead of an amplifier module.
- Line level output module
- Use of active loudspeakers
- Recording
- Amplifier for non-emergency applications, e.g. for subwoofers
- To be installed instead of ampilifier module
- Transformer-balanced
- Volume control
Specifications for product:
| VX-300LO | |
|---|---|
| Power source |
Supplied from VX-3000 frame |
| Current consumption (value) |
2 mA |
| Current consumption |
2 mA |
| Frequency response |
40 Hz - 20 kHz (±1 dB) |
| Audio output |
Transformer balanced, 3-pin removable screw terminal |
| Operating temperature. |
0°C - +40°C |
| Operating humidity. |
90% RH or less, no condensation |
| Dimensions. |
76 x 39 x 33.2 mm (W x H x D) |
| Finish. |
Steel, surface-treated |
