Product Description
TOA U-01P Line Input Module With Phone Jack
The U-01P is a line input module to be used in conjunction with the 900 series components and other TOA's equipment. It has an unbalanced line input with φ6.3 (1/4") phone jack connector, and gain control.
SPECIFICATIONS:
Power Source | 24 V DC (supplied from the main frame) |
---|---|
Current Consumption | 4 mA |
Input Sensitivity | -20 dB* (rated output: -20 dB*), adjustable: -20 to +10 dB* |
Input Impedance | 220 kΩ, unbalanced |
Frequency Response | 20 Hz - 20 kHz ±1.0 dB |
Distortion | 0.05 % or less (1 kHz, output: 0 dB*) |
Noise Level | -106 dB* (20 Hz - 20 kHz BPF) |
Gain | -30 - 0 dB |
Connector | φ6.3 (1/4) Phone jack (3P)" |
Dimensions | 35 (W) × 78 (H) × 88 (D) mm (1.38 × 3.07" × 3.46")" |
Weight | Max. 75 g (0.17 lb) |
