Product Description
Toa TZ-606WWP AS Column Speaker 60W/100V, 30W/70V
Overview
The TZ Series Column Speakers are highly efficient compact speakers that deliver excellent sound performance in medium sized venues such as houses of worship, gymnasiums, auditoriums and more.
Features
- Column Speaker is suitably designed for in-door use and/or outdoor use.
- Efficient for use in a spacious room.
- The speaker unit is designed to reproduce sound with good clarity and high input power capacity.
- The plastic column speaker comes with speaker bracket as accessories.
- The speaker bracket offers better installation flexibility.
Specifications
Enclosure: Sealed Type
Rated Input: 60 W
Rated Impedance
100 V line: 170 Ω (60 W), 330 Ω (30 W), 670 Ω (15 W), 1.3 kΩ (7.5 W)
70 V line: 170 Ω (30 W), 330 Ω (15 W), 670 Ω (7.5 W), 1.3 kΩ (3.8 W)
70 V line: 170 Ω (30 W), 330 Ω (15 W), 670 Ω (7.5 W), 1.3 kΩ (3.8 W)
Sensitivity: 94 dB (1 W, 1 m)
Frequency Response: 150 Hz - 13,000 Hz
Speaker Component: 10 cm (4") PP cone type x 6
Input Terminal: Push-In terminal
Finish
Enclosure: HIPS, white
Punched Net: Surface-tread steel plate, white, paint
Speaker Bracket: Aluminum die-cast, white, paint
Joint Bracket, Wall Bracket: Steel plate, t:1.6mm, white, paint (ED coating)
Punched Net: Surface-tread steel plate, white, paint
Speaker Bracket: Aluminum die-cast, white, paint
Joint Bracket, Wall Bracket: Steel plate, t:1.6mm, white, paint (ED coating)
Dimensions: 135 (W) x 746 (H) x 128 (D) mm (5.31" x 29.37" x 5.04")
Weight: 5.5 kg (12.12 lbs.) unit only
Included Accessories: Speaker Bracket x 1, Joint Bracket x 1, Wall Bracket x 1, Fixing Bolt (M5 x 60) x 1, Hexagon Bolt (M6 x 12) (with plain washer and spring washer) x 2, Machine Screw (M5 x 20) (with plain washer and spring washer) x 2, Hexagon Bolt (M8x 15) x 1, Tapping screw(4x12) x 4, Terminal Cover x 1
