Product Description
TOA SS-9001PS Four-Zone Speaker Selector
The SS-9001PS is SS9001 with AD-246. It is a speaker selector used in conjunction with the 9000 series amplifier. It outputs 2 input signals to 4 different zones.
SPECIFICATIONS:
Power Source | Supplied from the optional AD-246 AC adapter or an external 24 V DC/200 mA power supply. |
---|---|
Current Consumption | 120 mA |
Control Signal | No-voltage make contact input (polarized), open voltage: 24 V DC, short-circuit current: 3 mA |
Control Power | 240 W or less (70 V/100 V line) |
Speaker Terminal | Removable terminal block (2 pins) |
Control Terminal | Removable terminal block (10 pins) |
Operating Temperature | -10℃ to +40℃ |
Finish | Case: Surface-treated steel plate |
Dimensions | 112 (W) × 197 (H) × 30 (D) mm |
Weight | 530 g |
Accessory | Removable terminal plug (2 pins) …6, Removable terminal plug (10 pins) …1, Cord clamp …1, Mounting screw …4, AD-246...1 |
