Product Description
TOA S-04S Switch-Selectable Tone Generator
Generates one of four tones via switch-closure. Can be used for doorbell, paging, door/gate release, telephone night ringer, annunciator, class change or pre-announcement tone.
SPECIFICATIONS:
Power Source | 24 V DC (supplied from the main frame) |
---|---|
Current Consumption | 20 mA |
Output Level | 1.5 V (p-p) (Rated output: -20 dB*) |
Noise Level | -80 dB* (20 Hz - 20 kHz BPF) |
Gain | Off to 0 dB |
Available Tone | 1/2/4 Tone chime (selectable) |
Connector | Removable terminal block (3P) |
Dimensions | 35 (W) x 78 (H) x 88 (D) mm (1.38" x 3.07" x 3.46") |
Weight | Max. 70 g (0.15 lb) |
