Product Description
TOA RS-144 Dual Call Button Panel Switch
The RS-144 dual button call panel substation is designed to be used with the N-8000RS or N-8010RS substation interfaces. It provides Emergency (Red) and Normal (white) buttons that can be individually programmed to report to any master station based on job specification. It requires 3-conductor shielded twisted pair (STP) wiring and mounts in a standard US single gang flush or wall mount box. The optional RS-141 handset for private calling, or a 25V/1W speaker such as the PC-580RU for room announcement applications, can be connected to the call panel station.
SPECIFICATIONS:
Call-in Switch | Momentary (EMERGENCY, NORMAL) |
---|---|
Wiring | Two-core shielded cable |
Transmission Range | 0.5 km (546 yd)/φ0.5 mm (AWG24) 0.8 km (874 yd)/φ0.65 mm (AWG22) 1.3 km (1421 yd)/φ0.9 mm (AWG19) |
Operating Temperature | 0 ℃ to +40 ℃ (32 ゜F to 104 ゜F) |
Finish | Plate: Stainless steel, hairline Call-in Switch (emergency): resin, red Call-in Switch (normal) : resin, white |
Dimensions | 70 (W) × 115 (H) × 28.6 (D) mm (2.76 × 4.53" × 1.13")" |
Weight | 80 g (0.18 lb) |
Accessory | Mounting bracket ……1, bracket mounting screw (No.6-32UNC × 18) ……2, Box mounting screw (M4 × 30) ……2, Box mounting screw (No.6-32UNC × 30) ……2 |
