Product Description
TOA RM-200MPS Remote Microphone
Up to four remote microphones can be connected to the RM-200M Remote Microphone but the maximum connection length for all cables is approximately 800 meters. An external microphone input terminal is provided to allow using a headset microphone, along with built-in internal compressor circuitry to ensure broadcasts are always clear and distortion-free. The TALK button may be a PTT or lock-type, which also provides an "AUTO MIC Off" capability to automatically switch off the microphone if the TALK switch is inadvertently left on. The emergency activation button is equipped with a cover in case of accidental selection.
The VM-3000 Series UL 2572 and UL 864 listed, is ideal for small and medium-sized applications. It incorporates such emergency functions as continuous speaker line monitoring and a built-in voice alarm. This easy-to-install system also offers PA broadcasting, paging and BGM functions that ensure consistently high intelligibility. The VM-3000 Series is digitally audio processed and controlled, and may be set up and operated directly by using the controls and LCD display on the front panel. A dedicated PC software configuration capability is also provided for establishing settings via LAN. The incorporation of wide-ranging functional capabilities, superb reliability and versatility make the VM-3000 a highly cost-effective emergency broadcast system.
SPECIFICATIONS:
Power Source | 24 V DC (Operating range: 14 - 28 V DC) Power input jack: Non-polarity type Usable power input plug(*2): Outer diameter φ5.5 mm φ2.1 mm |
---|---|
Current Consumption | 100 mA or less |
Audio Output | 0 dB(*1) |
Distortion | 1% or less |
Frequency Response | 100 - 20 |
S/N Ratio | 60 dB or more |
Microphone | Unidirectional electret condenser microphone |
No. of Function Keys | 13 |
Emergency Broadcast(*3) | Activation of Emergency Broadcast (pre-recorded announcement or live microphone announcement) by Emergency Broadcast Switch |
Volume Control | Microphone volume control |
Connection Cable and Connector | Category 5 STP cable |
Finish | ABS resin |
Dimensions | 190 (W) × 76.5 (H) × 215 (D) mm (Gooseneck microphone excluded) |
Weight | 750 g |
Accessory | Link cable (3 m) ……1 |
Option | Wall mounting bracket: WB-RM200 |
