Product Description
TOA Q-PJ-304BK Projection Style Public Address Speaker
The Q-PJ-304BK projection style speakers are built within a bass-reflex HIPS resin enclosure 5" (12cm) cone-type projection speakers intended for ceiling and wall installation.
The Q-PJ-304BK also includes a balanced dome tweeter. They have an outstandingly stylish design that is inspired by the finest lighting fixtures, allowing them to be harmoniously installed with lighting equipment. They are ideally suited for such applications as BGM and announcements at airports, subway stations, art museums and shopping malls. The speakers are easy to repaint, extending the range of design needs they can meet. A supplied swivel bracket accessory allows for flexible speaker angle adjustment. Q-PJ-304BK is driven on a high- and low impedance (8 ohm) line. Input impedance is adjustable with rotary switch on the upper side of the speaker.
The Q-PJ-304BK is backed with a five year warranty.
SPECIFICATIONS:
Enclosure | Bass-reflex type |
---|---|
Rated Input | 30 W (100 V, 70 V line, 8 Ω) |
Rated Impedance | 100 V line: 330 Ω (30 W), 500 Ω (20 W), 670 Ω (15 W), 1 kΩ (10 W), 2 kΩ (5 W) 70 V line: 170 Ω (30 W), 250 Ω (20 W), 330 Ω (15 W), 500 Ω (10 W), 1 kΩ (5 W) 8 Ω |
Sensitivity | 91 dB (1 W, 1 m) (500 - 5,000 Hz, pink noise) |
Frequency Response | 70 - 20,000 Hz (peak -20 dB) |
Speaker Component | 12 cm (5") cone-type + balanced dome-tweeter |
Speaker Cord | 2-core cabtyre cord 60 cm (1.97 ft) with diameter of 6 mm (0.24") |
Finish | Enclosure: HIPS resin, black Grille: Surface-treated steel plate net, black, paint |
Dimensions | φ186 × 369 (H) mm (φ7.32" × 14.33") |
Weight | 2.1 kg (4.63 lb) (unit only) |
Accessory | Swivel bracket …1, Speaker mounting screw (4 × 16) …3 |
