Product Description
TOA N-8010EX IP Intercom Exchange
The N-8010EX IP Intercom Exchange uses packet audio technology to permit connection of up to 16 N-8000 series 2-wire master or door stations. Master stations and door stations use the same unshielded twisted pair wiring. Each N-8010EX supports one voice link. The N-8010EX supports the audio trigger function. The exchange may be used as a stand-alone system (requires at least one master station) or connected to an N-8000 IP intercom system over LAN or WAN. Rack mount and wall mount hardware are included.
The latest software version is 4.2.2 (update:2020/6/18), with previous versions 4.2.0(update:2015/04/03), 4.10(update:2014/11/13),and 1.41(update:2008/10/06). The Maintenance Software(Ver.1.2.0) is used to monitor or maintain equipment within the system(upload:2015/04/03).
Power Source |
120 V AC, 50/60 Hz |
Power Consumption |
50 W (at rated), 75 W (max.) |
Interface Section for station |
Number of lines: 16 lines Number of speech link: Internal: 1/External: 2 Type of Speech Path: Space sharing/Time Space sharing Transmission system: 2 wire 160 kbps echo canceller transmission system Signal Level: 0 dB* or less Transmission range: Max. 1500 m (φ0.65 mm, Loop resistance 170 Ω) Speech method: Simultaneous conversation by way of echo canceller (Hands-free), Connector: Dedicated connector Wiring method: 1 set of twisted pair cable Feeding voltage/current: 48 V DC, Max. 70 mA |
Paging Output |
Station paging only |
Network Section |
Network I/F: 10BASE-T/100BASE-TX (Automatic-Negotiation) Network protocol: TCP/IP, UDP, HTTP, RTP, ARP, ICMP, IGMP Audio packet transmission system: Unicast, Multicast Number of paging destinations: Unicast (max. 16), Multicast (max. 191) Connector: RJ45 connector Voice sampling frequency: 16 kHz, 8 kHz (controllable on the software) Quantifying bit number: 16-bit Voice encoding method: Sub-band ADPCM, Cryptosystem Voice packet loss recovery: Silence insertion Audio delay time: 80 ms, 320 ms (controllable on the software) |
Indication |
Network LNK/ACT indication, Status lamp, Power-on indication lamp |
Others |
Firmware update function, System registration data entry hold facility, Time of day hold facility, Forced air cooling, Reset switch (front panel) |
Setting Method |
Rack, Desk, Surface mount |
Operating Temperature |
0 ℃ to +40 ℃ |
Operating Humidity |
90 %RH or less (no condensation) |
Finish |
Pre-coated steel plate, black, 30 % gloss |
Dimensions |
420 (W) x 44.3 (H) x 356 (D) mm |
Weight |
4.2 kg |
Accessory |
AC power cord (2 m) …1, CD (for PC setting, maintenance use) …1, Mini-clamp plug (2 pins) …20, Plastic foot …4, Screw for fitting plastic foot …4, Rack mounting bracket …2, Screw for rack mounting …4, Wall mounting bracket …2, Screw for mounting bracket …8, Screw for wall mounting …4 |

Other Details
Limited Product Warranty - United States
PRODUCTS ARE ONLY INTENDED FOR COMMERCIAL (NON-CONSUMER) USES AND APPLICATIONS
TOA ELECTRONICS, INC. ("TEI") warrants Products purchased in the 50 United States of America and the District of Columbia against defects in material or workmanship, as follows:
Audio Products: Five years
Intercom Products: Two years
For warranty coverage of products of third parties resold through TEI, please contact the Original Equipment Manufacturer (OEM) or third party vendor directly.
Exceptions to Warranty Coverage
All Product Categories
Rust and/or corrosion of any Product and/or associated mounting hardware. This exception also applies to all Products which are recommended for outdoor applications.
Batteries
Battery failures: TOA will replace failed batteries within 60 days from the date of Product purchase. Purchaser should contact a TOA Authorized Reseller to arrange for the replacement.
Warranty Exclusions
Cases and case panels, grilles, lost or missing knobs, meter movements, wooden parts, damage caused by improper electrical service (such as power surge, brownout, operation on incorrect power supply) and shipping damage.
All claims under this Limited Product Warranty must be for covered problems and must be made during the applicable warranty period. To make a claim, Purchaser must return the Product, freight prepaid, to TEI's Service Center under a Return Merchandise Authorization issued by TEI in accordance with its then currently published procedure. The Product must be returned in either its original carton or a similar package affording an equal degree of protection. TEI will return the repaired Product freight prepaid to Purchaser. Unless the Product is covered by the Advance Replacement Policy then currently in effect by TEI, if any, TEI is not obligated to provide Purchaser with a substitute product during the warranty period or at any other time.
