Product Description
Toa MP-16PS 16 Channel Audio Monitor Panel
Overview
The MP-16 is a 16-channel audio monitor panel, which can be mounted on an EIA standard equipment rack (2 unit size). It allows monitoring 25/70/100 V high impedance speaker line, low impedance speaker line and line level audio signals by LED level meters. One of the 16 channels audio can be monitored with a built-in speaker or an optional headphone.
Features
- 16 channels audio monitoring
- Visual monitoring with 12-segments LED meters
- Aural monitoring by built-in speaker and optional headphones
- A variety of input capacity: line level, low-z spealer lines and 25/70/100V hi-z speaker lines
- EIA standard rack mounting (2 unit size)
- Dedicated AC adapter input and direct DC24V input terminal
Includes: AD-246 Power Supply
Specifications
Power Source
Supplied from an external 24 V DC (20-33 V) power supply, Removable terminal block (2 pins) or AC adapter AD-246 (option)
Current Consumption
520 mA (max.)
Input
High impedance speaker: Max. 100 V
Low impedance speaker: Max. 1200 W (8 Ω)
Line: +6 dB (*1)
Low impedance speaker: Max. 1200 W (8 Ω)
Line: +6 dB (*1)
Output
Speaker Output: Max. 3 W
Headphone Output: 8 Ω
Headphone Output: 8 Ω
Level Display
Meter: 12-segment LED meter x16
Level Indications: 1.6 - 100 V (High impedance speaker)
0.3 - 1200 W (Low impedance speaker)
-30 to +6 dB (*1) (Line)
Level Indications: 1.6 - 100 V (High impedance speaker)
0.3 - 1200 W (Low impedance speaker)
-30 to +6 dB (*1) (Line)
Operating Temperature
0 °C to +40 °C (32 °F to 104 °F)
Operating Humidity
90 %RH or less (no condensation)
Finish
Panel: Pre-coated steel plate, black, 30 % gloss
Case: Surface-treated steel plate
Case: Surface-treated steel plate
Dimensions
482 (W) x 88.4 (H) x 240.8 (D) mm (18.98" x 3.48" x 9.48")
Weight
3.9 kg (8.6 lb)
