Product Description
TOA FB-3862CU-AM Ceiling Subwoofer
The FB-3862CU is a high-performance flush-mount ceiling subwoofer assembly for low frequency enhancement of distributed loudspeaker systems. A 60W 70/100V transformer is included, and the bandpass design eliminates the need for a bi-amplified system. The 8-Ohm bypass allows for applications using electronic crossovers and dedicated low impedance power amplifiers. The FB-3862CU subwoofer rounds out TOA's F-Series premier speaker line to offer a full spectrum sonic experience suitable for retail environments, restaurants, lounges, conference rooms, and any application where music or video content require high quality sound.
Enclosure | Bandpass |
Rated Input | 60W (70/100V) |
Power Handling Capacity |
100W RMS 200W Peak (low impedance) |
Impedance | 70V line- 60W/30W/15W/7.5W/3.8W/1.9W with 8 Ω bypass |
Sensitivity | 91dB 1W/1m |
Frequency Response | 45-200 Hz (-10dB) |
Speaker Component | 8” driver with oiled paper cone and foam surround |
Certification | UL2043/UL1480A. Baffle meets UL 94-V0 flammability rating. RoHS and CE compliant |
Mounting Hole | 350mm diameter (13.8") |
Input Terminal | Phoenix-type with parallel outputs (max 12AWG stranded cable) |
Recommended Cable | Max 12AWG stranded unshielded twisted pair (jacket per code) |
Finish | White |
Dimensions | 383 mm diameter x 326.5 mm height (15.08" x 12.85") |
Weight | 6.45 kg (14.22 lbs.) |
Included Accessories | Steel support ring (C-ring) qty. 2, steel support rails qty.2, speaker hole template qty.2, operation manual qty. 1 |
Option Accessories | Support and safety cables (load rated chain or load rated aircraft cable) |
(*1) 0 dB = 1 V
