Product Description
TOA A-848D 480W 800D Series Digital Mixer Amplifier
This digital mixer amplifier provides maximum flexibility with up to eight inputs and up to 480 W of power. Browser based control and monitoring from anywhere reduces your time troubleshooting and adjusting systems. Onboard DSP, a sleek new appearance, optional MOH output, two available 900 series module slots and TOA's legendary quality and reliability makes this a perfect fit for background and foreground music, paging, and noise masking applications.
SPECIFICATIONS
| Power Source | 120 V AC, 60 Hz | ||||
| Rated Output | 480 W | ||||
| Power Consumption | 621 W (rated output), 103 W (based on UL62368) 200 mA or less (when power switch is OFF) | ||||
| Frequency Response | 50 Hz to 20 kHz ±3 dB (1/8 rated output) | ||||
| Total Harmonic Distortion | 1 % or less at 1 kHz, rated power (20 kHz LPF (AUX-0025)) | ||||
| Tone Control | Bass: ±10 dB at 100 Hz, Treble: ±10 dB at 10 kHz | ||||
| Signal to Noise Ration | 88 dB or more (Master volume: min) 76 dB or more (Master volume: max) 55 dB or more (INPUT 1 to 6) (A-weighted) | ||||
| Input | 1-2: | -60 dB* (MIC)/-20 dB* (LINE) selectable, 600 Ω, electronically-balanced, removable terminal block (3.81 mm, 3 pins) Note: MIC inputs are equipped with phantom power (24 V DC, ON/OFF switchable). | |||
| 3-4: | -60 dB*, 600 Ω, electronically-balanced, removable terminal block (3.81 mm, 3 pins) Note: Equipped with phantom power (24 V DC, ON/OFF switchable). | ||||
| 5-6: | MIC/LINE selectable MIC: -60 dB* , 600 Ω, electronically-balanced, removable terminal block (3.81 mm, 3 pins) LINE: -20 dB*, 10 kΩ, unbalanced, RCA pin jack x 2 | ||||
| Module 1-2 | -20 dB*, 10 kΩ | ||||
| Output |
Speaker | High impedance: 70 V line/10 Ω Low impedance 4 to 16 Ω selectable | |||
| REC: | 0 dB *, 600 Ω, unbalanced, RCA pin jack x 2 | ||||
| PRE AMP: | 0 dB *, 600 Ω, unbalanced, RCA pin jack | ||||
| Control Input | 4 channels, no-voltage make contact input, open voltage: 35 V DC or less, Short-circuit current: 10 mA or less, removable terminal block (3.81 mm, 4 pins) | ||||
| REMOTE VOLUME: No-voltage make contact input, open voltage: 35 V DC or less, Short circuit current: 10 mA or less, removable terminal block (3.81 mm, 4 pins) | |||||
| Control Output | POWER REMOTE: Open collector output, withstand voltage: 30 V DC or less, control current: 25 mA or less, removable terminal block (3.50 mm, 4 pins) | ||||
| EMERGENCY OUT: Open collector output, withstand voltage: 30 V DC or less, control current: 25 mA or less, removable terminal block (3.50 mm, 4 pins) | |||||
| Indicators | LED level meter, Power indicator, Network connection confirmation indicator, Priority broadcast indicator, Emergency broadcast indicator, Thermal protection indicator, Over-current protection indicator, CPU running indicator, Error indi-cator | ||||
| Operating Temperature | -10 to +40 ËšC (14 to 104 ËšF) | ||||
| Operating Humidity | 85 % RH or less (no condensation) | ||||
| Finish | Panel: ABS resign, black Case: Surface-treated steel plate, black, paint |
||||
| Dimensions | 420 (w) x 96.1 (h) x 313.1 (d) mm or 16,54" x 3.78" x 12.33" | ||||
| Weight | 5.4 kg or 11.9 lb | ||||
| Options | Input transformer: IT-450, Perforated panel: PF-013B |
||||
* 0 dB = 1 V
Note: The design and specifications are subject to change without notice for improvement.
