Product Description
Tascam RC-10 Remote Control For DR-40, DR-100Mkii
Eliminating touch noises while recording on the TASCAM DR-series
The RC-10 is a wired/wireless convertible remote control for TASCAM DR-series that eliminates touch noises while recording, supporting wireless control from a distant place in either wired or wireless.
Wired or wireless convertible remote control unit for TASCAM DR-series.
- Wired remote control for DR-100, DR-100MKII, DR-100MKIII, DR-60, and DR-40
- Infra-red wireless remote control for DR-100 and DR-100MKII
- Four function keys
- Wired remote control adapter with belt clip
- Detachable 10ft. (3m) cable with 2.5mm TRS plugs
- CR2025 Lithium battery operation for wireless mode
- DC power operation when wired mode
Spec description
Compatible models | |
Wireless mode | DR-100MK, DR-100MKII |
Wired mode | DR-100, DR-100MKII, DR-100MKIII, DR-60, DR-40 |
TRS connection | 2.5mm TRS Plug (Tip: SIGNAL, Ring: DC3.3V, Sleeve: GND) |
Power | |
Wireless mode | CR2025 Lithium ion battery |
Wired mode | DC 3.3V (from a connected unit) |
Power consumption | 3mW |
Dimensions (W×H×D) | |
Wireless mode | 1.30" × 0.28" × 3.39" / 33 × 7 × 86 mm |
Wired mode | 1.46" × 0.55" × 4.33" / 37 × 14 × 110 mm |
Weight | 0.53 oz. / 14.6 g (excluding battery, wired remote control adapter and cable) |
Operating temperature | 41˚F to 95˚F / 5˚C to 35˚C |
Included accessories | CR2025 Lithium ion battery, Wired remote control adapter, Cable (10ft. / 3m), Owner's Manual |
Functions
F-key signal assignment | |||
F1 | F2 | F3 | F4 |
1 / 2 [ SOLO ] | 3 / 4 [ SOLO ] | INPUT VOL + | INPUT VOL - |
