Tascam IF-MA64/BN 64-Channel MADI Coaxial Interface Card
Overview
The IF-MA64/BN is an optional 64-in/64-out MADI interface card for the TASCAM expansion slot system. Equipped with coaxial input and output connectors.
Supporting Models: TASCAM Sonicview 24XP / TASCAM Sonicview 16XP / DA-6400 / DA-6400dp
Features
- Up to 64-in/64-out (48kHz/44.1kHz) or up to 32-in/32-out (96kHz/88.2kHz) MADI inputs and outputs
- 75Ω COAXIAL input and output connectors
- LOCK indicator for confirming valid input signal
- Compatible with the TASCAM Expansion Slot system
Specifications
- Sampling Frequency 44.1k/48kHz : 48k frame、56/64 channels
- Sampling Frequency 88.2k/96kHz : 48k frame、28/32 channels 96k frame、28/32 channels
- MADI COAXIAL IN connector : BNC coaxial 75Ω
- MADI COAXIAL IN connector : AES10-2008
- MADI COAXIAL OUT connector : BNC coaxial 75Ω
- MADI COAXIAL OUT connector : AES10-2008
- Dimensions : 107(W) × 34(H) × 164.4(D) mm (including protrusions)
- Weight : 137g
