Product Description
Tascam DP-24SD 24-Track Digital Portastudio
No simpler choice than the DP-24SD, for complete music production on a desktop
The DP-24SD Digital Portastudio is a 24-track workstation, allowing eight tracks of simultaneous recording. The built-in mixer includes everything you need for a professional-sounding mix, from EQ and reverb to amp simulation and multi-band mastering effects. The Digital Portastudio series creates finished productions without the need for a computer, instead using a simple-to-use control surface to keep you creative.
User interface that delivers hassle-free recording
The concept behind the PORTASTUDIO series, which has a history spanning over 30 years, is one of intuitive operation.
The series’ biggest feature is its hassle-free user interface built upon this concept.
Various full-color LCD screens and self-illuminated buttons offer superb visibility.
Furthermore, the same number of faders as tracks have been included, eliminating layer structuring and making volume control more intuitive.
These measures have been taken to provide the user with a music production experience free of hassle.
Simultaneous 8-track recording with 8 XLR/TRS combo connectors
The DP-24SD has 8 XLR/TRS combo inputs that can withstand multi-microphone recording with drums.
Phantom power supply is also possible, including direct guitar input. With dynamic effects, which are indispensable for high-quality recording, up to 8 effects can be selected for inputs simultaneously.
In addition, the DP-24SD comes with built-in guitar multi-effects, tuner, and metronome, allowing users to complete recording preparations with this device alone.
This means the time you would normally spend on preparation is freed up for music production instead.
upports high-quality mixing thanks to its professional effects
When it comes to mixing, users can perform a speedy mix-down with intuitive operation thanks to the full-color LCD, encoders, and faders of the DP-24SD.
Mixing effects that are available include reverbs and spatial effects that you can use to enhance your music, resulting in audio with quality as high as that of professional studio productions.
After mixing is done, final touches can be added by using the built-in mastering effect.
From the moment you switch the device on to mastering your audio production, the DP-24SD creates a professional production environment without a computer
Even in loud environments, the high output powered amplifier makes headphone monitoring easy
In order to ensure a high-quality production environment, the outputs and monitor systems have been upgraded.
Separate to the stereo output, a MONITOR OUT that can adjust monitor volume has been installed, capable of making balanced connections even with large monitor speakers. In addition, headphone amplifier that allows loud volume monitoring has also been installed.
The DP-24SD DIGITAL PORTASTUDIO is a recording system in which musicians can perform essential professional band recording and audio production at the comfort of their own home.
Stress-free user interface for easy recording
19 faders eliminates layer structuring
Nineteen track faders and one master fader allows instant access to any track without selecting pages or banks of faders.
A 3.5" full-color LCD and self-illuminated buttons for increased visibility
Some of the illuminated buttons include (SOURCE, SELECT, REC, MUTE).
12 rotary knobs are linked to the LCD for easy operation
Solid-state SD/SDHC media ensures confident recording, free from shock and vibration
File format of the DP-24SD is FAT 16 or 32.
The Portastudio recorded files can be accessed on your computer when connected via USB.
8 XLR/TRS inputs, 8 channel recording, 24 track playback
INPUT A-H and each track are equipped with 3-band EQ
Record like any professional studio with EQ for each individual track.
8 dynamics effects, guitar effects and mix-down effects
When the mutlieffects processor is used, only four dynamics effects are available. The stereo reverb on send/return 1 is always available.
Mastering effects provided without the need for other devices
In the mastering effect section you will find a 3-band equalizer, a 3-band multiband compressor and 3 normalize effects for setting peak amplitude - take your stereo master file to the next level of quality.
The headphone amplifier has a high output power of 70mW/ch
RCA stereo output and two unbalanced 1/4" TS outputs
High-impedance input available on INPUT H when set to GUITAR
Phantom power supplied on all inputs
Dedicated MONITOR OUT for monitor speakers
Remote connector for optional RC-3F foot switch
atures at a glance
- Simultaneous 24-track playback
- 12 mono tracks + 6 stereo tracks
- Simultaneous 8-track recording
- 44.1k or 48k Hz, 16 or 24-bit recording
- 8 XLR/TRS combo connectors
- Phantom power supplied on all inputs (INPUT A-D,E-H)
- High-impedance input available (INPUT H)
- Stereo RCA output
- 2 effect send outputs (1/4" TS jack)
- 70mW/ch headphone amplifier
- Remote connector for optional RC-3F foot switch
- INPUT A-H and each track equipped with 3-band EQ
- Automatic punch in/out
- Various edit functions (COPY INSERT, COPY PASTE, MOVE INSERT, MOVE PASTE, OPEN, CUT, SILENCE, CLONE TRACK, CLEAN OUT)
- Undo and Redo function with Undo history
- Dynamics effects for input (Limiter, Compressor, Noise Suppressor, Exciter)
- Guitar effects (Amp Simulator, Reverb, Compressor, Chorus, Flanger, Phaser)
- Mix-down effects (Reverb, Delay, Stereo Chorus)
- Mastering Effects (Multi-band Compressor, Equalizer, Dither, Normalize)
- Track bounce function
- Virtual track (8 virtual track per one track: including use track)
- Locate mark up to 99 for one song
- File transferring via USB2.0
- Chromatic tuner
- Metronome
- 19 Faders
- Peak-hold function on the level meter of the LCD
- Sub-frame editing
- Dedicated AC adapter included (TASCAM GPE248-120200-Z)
- SD card included
- RoHS certified
Spec description
Recording Media | SD (512MB to 2GB) / SDHC card (4GB to 32GB) |
File System | SD card: FAT16 / SDHC card: FAT32 |
INPUT A-H | |
XLR | |
Connector | XLR-3-31 (1: GND, 2: HOT, 3: COLD), Balanced |
Input impedance | 2.4kΩ |
Nominal input level | –14dBu |
Maximum input level | +2dBu |
TRS | |
Connector | 1/4" (6.3mm) TRS phone jack, Balanced |
Input impedance | 22kΩ or more / 1MΩ (when INPUT H, GUITAR selected) |
Nominal input level | +4dBu |
Maximum input level | +20dBu |
STEREO OUT | |
Connector | RCA pin-jack, Unbalanced |
Output impedance | 200Ω |
Nominal output level | –10dBV |
Maximum output level | +6dBV |
EFFECT SENDS | |
Connector | 1/4" (6.3mm) TS phone jack, Unbalanced |
Output impedance | 200Ω |
Nominal output level | –10dBV |
Maximum output level | +6dBV |
MONITOR OUT | |
Connector | 1/4" (6.3mm) TRS phone jack, Balanced |
Output impedance | 200Ω |
Nominal output level | –2dBu |
Maximum output level | +14dBu |
PHONES | |
Connector | 1/4" (6.3mm) stereo phone jack |
Maximum output level | 70mW + 70mW (THD+N 0.1% or less, 32Ω loaded) |
USB | |
Connector | USB Mini-B type 4-pin |
Format | USB2.0 High-Speed mass-storage class |
REMOTE | |
Connector | 2.5mm TRS jack |
Power | Dedicated AC adapter (TASCAM GPE248-120200-Z, included) |
Power consumption | 12W (when phantom power supplying) |
Dimensions (W×H×D) | 20.2" × 4.1" × 13.4" / 514 × 100.4 × 336.9 mm |
Weight | 13.67 lbs. / 6.2 kg |
Accessories | AC adapter, 4GB SD card, warranty card, owner's manual |
Audio performance | |
Frequency response | 20Hz to 20kHz (±1dB, INPUT to STEREO OUT/EFFECT SENDS/MONITOR OUT) |
S/N Ratio | 90dB or greater (INPUT to STEREO OUT/EFFECT SENDS/MONITOR OUT) |
THD | 0.01% or less (INPUT to STEREO OUT/EFFECT SENDS/MONITOR OUT) |
Operating system requirements | |
Windows | |
OS | Windows XP, Windows Vista, Windows 7, Windows 8 |
CPU | Pentium 300MHz or more |
Memory | 128MB or more |
USB | USB2.0 |
Macintosh | |
OS | Mac OS X Snow Leopard (V10.6), OS X Lion (V10.7), OS X Mountain Lion (V10.8), OS X Mavericks (V10.9) |
CPU | Power PC, iMAC, G3, G4 266MHz or more |
Memory | 64MB or more |
USB | USB2.0 |
Supported Media
Maker | Series | Model | Capacity |
---|---|---|---|
Lexar | Lexar® Platinum II 100x SDHC™ Memory Card (Class10) | LSD16GBCJP100C10 | 16GB |
Lexar | Lexar® Platinum II 100x SDHC™ Memory Card (Class10) | LSD32GBCJP100C10 | 32GB |
Lexar | Lexar® Platinum II 100x SDHC™ Memory Card (Class6) | LSD32GBCJP100 | 32GB |
Lexar | Lexar® Platinum II 100x SDHC™ Memory Card (Class6) | LSD4GBBCJP100 | 4GB |
Lexar | Lexar® Platinum II 100x SDHC™ Memory Card (Class6) | LSD8GBBCJP100 | 8GB |
Lexar | Lexar® Platinum II 200x SDHC™ UHS-I Memory Card (Class10) | LSD16GBBJP200 | 16GB |
Lexar | Lexar® Platinum II 200x SDHC™ UHS-I Memory Card (Class10) | LSD32GBBJP200 | 32GB |
Lexar | Lexar® Platinum II 200x SDHC™ UHS-I Memory Card (Class10) | LSD8GBBBJP200C10 | 8GB |
Lexar | Lexar® Platinum II 60x SDHC™ Memory Card (Class4) | LSD16GBCJP060 | 16GB |
Lexar | Lexar® Platinum II 60x SDHC™ Memory Card (Class4) | LSD32GBCJP060 | 32GB |
Lexar | Lexar® Platinum II 60x SDHC™ Memory Card (Class4) | LSD4GBBCJP060 | 4GB |
Lexar | Lexar® Platinum II 60x SDHC™ Memory Card (Class4) | LSD8GBBCJP060 | 8GB |
Lexar | Lexar® Professional 133x SDHC™ Memory Card | LSD8GBDRBJP133 | 8GB |
Lexar | Lexar® Professional 133x SDHC™ Memory Card (Class10) | LSD16GCRBJP133 | 16GB |
Lexar | Lexar® Professional 133x SDHC™ Memory Card (Class10) | LSD32GCRBJP133 | 32GB |
Lexar | Lexar® Professional 133x SDHC™ Memory Card (Class6) | LSD4GBDRBJP133 | 4GB |
Lexar | Lexar® Professional 400x SDHC™ UHS-I Memory Card (Class10) | LSD16GCTBJP400 | 16GB |
Lexar | Lexar® Professional 400x SDHC™ UHS-I Memory Card (Class10) | LSD32GCTBJP400 | 32GB |
Lexar | Lexar® Professional 400x SDHC™ UHS-I Memory Card (Class10) | LSD8GBCTBJP400 | 8GB |
Lexar | Lexar® Professional 600x SDHC™ UHS-I Memory Card (Class10) | LSD16GCTBJP600 | 16GB |
Lexar | Lexar® Professional 600x SDHC™ UHS-I Memory Card (Class10) | LSD32GCTBJP600 | 32GB |
Lexar | Lexar® Secure Digital (SD™) Memory Card (MULTI USE) | LSD2GBACJP | 2GB |
Lexar | Lexar® Secure Digital High Capacity (SDHC™) Memory Card (Class2) | LSD4GBACJP | 4GB |
Lexar | Lexar® Secure Digital High Capacity (SDHC™) Memory Card (Class2) | LSD8GBACJP | 8GB |
Lexar | Lexar® Secure Digital High Capacity (SDHC™) Memory Card (Class6) | LSD16GABJPCL6 | 16GB |
Lexar | Lexar® Secure Digital High Capacity (SDHC™) Memory Card (Class6) | LSD32GABJPCL6 | 32GB |
Lexar | Lexar® Secure Digital High Capacity (SDHC™) Memory Card (Class6) | LSD8GBABJPCL6 | 8GB |
Lexar | Lexar® Standard SDHC™ Memory Card (Class4) | LSD16GACJP | 16GB |
Lexar | Lexar® Standard SDHC™ Memory Card (Class4) | LSD32GACJP | 32GB |
Lexar | Lexar® Super Value SDHC™ Memory Card (Class4) | LSD4GBASVDJP | 4GB |
Lexar | Lexar® Super Value SDHC™ Memory Card (Class4) | LSD8GBASVDJP | 8GB |
Panasonic | Premium PRO SDHC™ UHS-I Memory Card (Class10) R:95MB/s W:80MB/s | RP-SDAB08GJK | 8GB |
Panasonic | Premium PRO SDHC™ UHS-I Memory Card (Class10) R:95MB/s W:80MB/s | RP-SDAB16GJK | 16GB |
Panasonic | Premium SDHC™ UHS-I Memory Card (Class10) R:90MB/s W:45MB/s | RP-SDUB08GJK | 8GB |
Panasonic | Premium SDHC™ UHS-I Memory Card (Class10) R:90MB/s W:45MB/s | RP-SDUB16GJK | 16GB |
Panasonic | Premium SDHC™ UHS-I Memory Card (Class10) R:90MB/s W:45MB/s | RP-SDUB32GJK | 32GB |
Panasonic | SDHC (UHS-I / Class10) R:90MB/s W:25MB/s | RP-SDU08GJ1K | 8GB |
Panasonic | SDHC (UHS-I / Class10) R:90MB/s W:25MB/s | RP-SDU16GJ1K | 16GB |
Panasonic | SDHC (UHS-I / Class10) R:90MB/s W:45MB/s | RP-SDUC32GJK | 32GB |
Panasonic | SDHC (UHS-I / Class10) R:95MB/s W:80MB/s | RP-SDA08GJ1K | 8GB |
Panasonic | SDHC (UHS-I / Class10) R:95MB/s W:80MB/s | RP-SDA16GJ1K | 16GB |
Panasonic | SDHC (UHS-I / Class10) R:95MB/s W:80MB/s | RP-SDA32GJ1K | 32GB |
Panasonic | SDHC Memory Card (Class6) R:20MB/s | RP-SDLC04GJK | 4GB |
Panasonic | SDHC Memory Card (Class6) R:20MB/s | RP-SDLC08GJK | 8GB |
Panasonic | SDHC Memory Card (Class6) R:20MB/s | RP-SDLC16GJK | 16GB |
Panasonic | SDHC Memory Card (Class6) R:20MB/s | RP-SDLC32GJK | 32GB |
Panasonic | SDHC™ Memory Card (Class10) | RP-SDW04GJ1K | 4GB |
Panasonic | SDHC™ Memory Card (Class10) | RP-SDW08GJ1K | 8GB |
Panasonic | SDHC™ Memory Card (Class10) | RP-SDW16GJ1K | 16GB |
Panasonic | SDHC™ Memory Card (Class10) | RP-SDW32GJ1K | 32GB |
Panasonic | SDHC™ Memory Card (Class10) R:20MB | RP-SDWA08GJK | 8GB |
Panasonic | SDHC™ Memory Card (Class10) R:20MB | RP-SDWA16GJK | 16GB |
Panasonic | SDHC™ Memory Card (Class10) R:20MB | RP-SDWA32GJK | 32GB |
Panasonic | SD™/SDHC™ Memory Card (Class4) | RP-SDP02GJ1K | 2GB |
Panasonic | SD™/SDHC™ Memory Card (Class4) R:20MB | RP-SDL02GJ1K | 2GB |
Panasonic | SD™/SDHC™ Memory Card (Class4) R:20MB | RP-SDL04GJ1K | 4GB |
Panasonic | SD™/SDHC™ Memory Card (Class4) R:20MB | RP-SDL08GJ1K | 8GB |
Panasonic | SD™/SDHC™ Memory Card (Class4) R:20MB | RP-SDL16GJ1K | 16GB |
Panasonic | SD™/SDHC™ Memory Card (Class4) R:20MB | RP-SDL32GJ1K | 32GB |
SanDisk | Extreme Pro SD UHS-II card | SDSDXPK-032G-JNJIP | 32GB |
SanDisk | Extreme® SDHC™ UHS-I Card (U3,Class10) | SDSDXNE-016G-JNJIP | 16GB |
SanDisk | SanDisk Extreme Pro® SDHC™ UHS-I Memory Card (Class10) | SDSDX-016G-J35 | 16GB |
SanDisk | SanDisk Extreme Pro® SDHC™ UHS-I Memory Card (Class10) | SDSDX-032G-J35 | 32GB |
SanDisk | SanDisk Extreme Pro® SDHC™ UHS-I Memory Card (Class10) | SDSDXPA-016G-J35N | 16GB |
SanDisk | SanDisk Extreme Pro® SDHC™ UHS-I Memory Card (Class10) | SDSDXPA-032G-J35N | 32GB |
SanDisk | SanDisk Extreme Pro® SDHC™ UHS-I Memory Card (Class10) | SDSDXS-008G-J35 | 8GB |
SanDisk | SanDisk Extreme Pro® SDHC™ UHS-I Memory Card (Class10) | SDSDXS-016G-J35 | 16GB |
SanDisk | SanDisk Extreme Pro® SDHC™ UHS-I Memory Card (Class10) | SDSDXS-032G-J35 | 32GB |
SanDisk | SanDisk Extreme Pro® SDHC™ UHS-I Memory Card | SDSDXP1-008G-J95 | 8GB |
SanDisk | SanDisk Extreme Pro® SDHC™ UHS-I Memory Card | SDSDXP1-032G-J95 | 32GB |
SanDisk | SanDisk Extreme Pro® SDHC™ UHS-I Memory Card (Class10) | SDSDXPA-016G-J35 | 16GB |
SanDisk | SanDisk Extreme Pro® SDHC™ UHS-I Memory Card (Class10) | SDSDXPA-032G-J35 | 32GB |
SanDisk | SanDisk Extreme Pro® SDHC™ UHS-II Memory Card | SDSDXPB-016G-J35 | 16GB |
SanDisk | SanDisk Extreme Pro® SDHC™ UHS-II Memory Card | SDSDXPB-032G-J35 | 32GB |
SanDisk | SanDisk Extreme Pro® SDHC™/ SDXC™ UHS-I Memory Card (U3, Class10) | SDSDXPA-016G-JU3 | 16GB |
SanDisk | SanDisk Extreme Pro® SDHC™/ SDXC™ UHS-I Memory Card (U3, Class10) | SDSDXPA-032G-JU3 | 32GB |
SanDisk | SanDisk Extreme® HD Video SDHC™ Memory Card (Class10) | SDSDX3-016G-J21N | 16GB |
SanDisk | SanDisk Extreme® HD Video SDHC™ Memory Card (Class10) | SDSDX3-4096-J21N | 4GB |
SanDisk | SanDisk Extreme® HD Video SDHC™ Memory Card (Class10) | SDSDX3-8192-J21N | 8GB |
SanDisk | SanDisk Extreme® PLUS SDHC™ UHS-I Memory Card (Class10) | SDSDXS-016G-J35P | 16GB |
SanDisk | SanDisk Extreme® PLUS SDHC™ UHS-I Memory Card (Class10) | SDSDXS-032G-J35P | 32GB |
SanDisk | SanDisk Extreme® SDHC™ UHS-I Memory Card (Class10) | SDSDX-004G-J95 | 4GB |
SanDisk | SanDisk Extreme® SDHC™ UHS-I Memory Card (Class10) | SDSDX-008G-J95 | 8GB |
SanDisk | SanDisk Extreme® SDHC™ UHS-I Memory Card (Class10) | SDSDX-016G-J95 | 16GB |
SanDisk | SanDisk Extreme® SDHC™ UHS-I Memory Card (Class10) | SDSDX-032G-J95 | 32GB |
SanDisk | SanDisk Extreme® SDHC™ UHS-I Memory Card (Class10) | SDSDXL-016G-J35 | 16GB |
SanDisk | SanDisk Extreme® SDHC™ UHS-I Memory Card (Class10) | SDSDXL-032G-J35 | 32GB |
SanDisk | SanDisk Extreme® SDHC™/ SDXC™ UHS-I Memory Card (U3, Class10) | SDSDXL-016G-JU3 | 16GB |
SanDisk | SanDisk Extreme® SDHC™/ SDXC™ UHS-I Memory Card (U3, Class10) | SDSDXL-032G-JU3 | 32GB |
SanDisk | SanDisk Extreme® SDHC™ Memory Card (Class10) | SDSDX3-004G-J31A | 4GB |
SanDisk | SanDisk Extreme® SDHC™ Memory Card (Class10) | SDSDX3-008G-J31A | 8GB |
SanDisk | SanDisk Extreme® SDHC™ Memory Card (Class10) | SDSDX3-016G-J31A | 16GB |
SanDisk | SanDisk Standard SD™/SDHC™ Memory Card (CLASS2) | SDSDB-8192-J95 | 8GB |
SanDisk | SanDisk Standard SD™/SDHC™ Memory Card (CLASS4) | SDSDB-008G-J01 | 8GB |
SanDisk | SanDisk Standard SD™/SDHC™ Memory Card (CLASS4) | SDSDB-032G-J95A | 32GB |
SanDisk | SanDisk Standard SD™/SDHC™ Memory Card (CLASS4) | SDSDB-2048-J95B | 2GB |
SanDisk | SanDisk Standard SD™/SDHC™ Memory Card (CLASS4) | SDSDB-8192-J95A | 8GB |
SanDisk | SanDisk Ultra® PLUS SDHC™ UHS-I Memory Card(Class10) | SDSDUM-016G-J01 | 16GB |
SanDisk | SanDisk Ultra® PLUS SDHC™ UHS-I Memory Card(Class10) | SDSDUP-008G-J35 | 8GB |
SanDisk | SanDisk Ultra® PLUS SDHC™ UHS-I Memory Card(Class10) | SDSDUP-016G-J35 | 16GB |
SanDisk | SanDisk Ultra® SDHC™ UHS-I Memory Card (Class10) | SDSDU-008G-J35 | 8GB |
SanDisk | SanDisk Ultra® SDHC™ UHS-I Memory Card (Class10) | SDSDU-016G-J35 | 16GB |
SanDisk | SanDisk Ultra® SDHC™ UHS-I Memory Card (Class10) | SDSDU-032G-J35 | 32GB |
SanDisk | SanDisk Ultra® SDHC™ UHS-I Memory Card (Class6) | SDSDH-004G-J35 | 4GB |
SanDisk | SanDisk Ultra® SD™/SDHC™ Memory Card (CLASS4) | SDSDH-002G-J95 | 2GB |
SanDisk | SanDisk Ultra® SD™/SDHC™ Memory Card (CLASS4) | SDSDH-004G-J95 | 4GB |
SanDisk | SanDisk Ultra® SD™/SDHC™ Memory Card (CLASS4) | SDSDH-008G-J95 | 8GB |
SanDisk | SanDisk Ultra® SD™/SDHC™ Memory Card (CLASS4) | SDSDH-016G-J95 | 16GB |
SONY | SDHC UHS-I Memory Card | SF-8UY2 | 8G |
SONY | SDXC/SDHC UHS-I Memory card SF-UY3 Series | SF-16UY3 | 16GB |
SONY | SDXC/SDHC UHS-I Memory card SF-UY3 Series | SF-32UY3 | 32GB |
SONY | SFUX Series SD Memory Card | SF-32UX2 | 32GB |
TASCAM | TSQD | TSQD-32A | 32GB |
TOSHIBA | EXCERIA PRO™ SDHC/SDXC Memory Card (SD-KU Series) | SD-KU016G | 16GB |
TOSHIBA | EXCERIA PRO™ SDHC/SDXC Memory Card (SD-KU Series) | SD-KU032G | 32GB |
TOSHIBA | EXCERIA™ SDHC/SDXC Memory Card(SD-FU Series) | SD-FU008G | 8GB |
TOSHIBA | EXCERIA™ SDHC/SDXC Memory Card(SD-FU Series) | SD-FU016G | 16GB |
TOSHIBA | EXCERIA™ UHS-I SDHC™Memory Card (U3, Class10) | SD-JU016G | 16GB |
TOSHIBA | EXCERIA™ UHS-I SDHC™Memory Card (U3, Class10) | SD-JU032G | 32GB |
