Product Description

SoundTube MM43-BGM Mighty Mite 4-inch, 3-way Hanging Speaker

Overview

The MM43-BGM is a 3-way pendant speaker with a 5.25” dual-chamber, band-pass subwoofer, a 4” woofer and a .75” BroadBeam® ring tweeter, with high-frequency dispersion technology for wide off-axis coverage. Mighty Mite’s subwoofer with phase-aligned bass produces even, full-range coverage, smooth response, and loud, clean sound from one point of origin. With its built-in subwoofer and expansive coverage over larger areas than conventional pendant speakers, the Mighty Mite generates exceptional sound for music and voice applications. In addition, the speaker’s wide coverage capabilities mean fewer speakers are needed thus further reducing both hardware and labor costs for the project.

Ideal for paging, background music, foreground music and most open-ceiling applications, the Mighty Mites have a built-in 30-Watt transformer for standard 25/70/100-volt applications or can be used as direct 8-ohm speakers. The unique driver combination gives unprecedented phase-matched audio between the low, mid, and high frequencies.

Mighty Mite has an integrated hanging bracket at the top of the speaker and comes with UL-listed hanging hardware with cables and integrated SpeedClamp™ self-locking wire grip for fast, easy, and secure installation. The MM43-BGM is 22” high with a 7.4” diameter, weigh 14 lbs.

Specifications

Manufacturer: SoundTube

Manufacturer's Category: MM/DS Contemporary Pendants

Height: 21.9 in / 556 mm

Width/Diameter: 7.4 in / 188 mm

Shipping Weight: 13.15 lbs. / 5.96 kg

Certifications: CE, RoHS, UL1480, UL2239

Enclosure Properties: ABS

Included Accessories: Hanging Hardware, Terminal Weather Boot

Source Inputs: 4 Pin Ceramic Terminal

Crossover Frequency: 100 Hz; 2.5 kHz

Frequency Response (± 10 dB): 37 Hz - 27 kHz

Frequency Response (± 3 dB): 62 Hz - 24 kHz

Grille Properties": Magnetic, Powder-Coated

Max. Continuous Power RMS: 30 W

Max SPL @ 1M: 103 dB

Max. Program Power: 60 W

Nominal Impedance (Ω Ohms): 8 Ω

Tweeter Driver: .75" Synthetic Soft Dome

Woofer Driver: 4" Polypropylene Cone with Butyl Rubber Surround

Subwoofer Driver: 5.25" Polypropylene Cone w/ Rubber Surround

Sensitivity dB @ 1W/1M: 84 dB

Sensitivity dB @ 2.83V/1M: 84 dB

Tap Selector: Rotary Switch

Transformer Options: Included 70.7 / 100 V transformer (30 W maximum)
