Product Description
SolidDrive SD250 50 Watts Per Channel Class D Amplifier
Overview
The SolidDrive SD-250 is an ultra compact 2-channel amplifier with extra heat sink surfaces for extended duty at full power. The amp is rated at 50 watts per channel and can run in stereo, mono, or bridged mono. But most importantly it has custom electronic EQs for glass, sheet rock, wood, or bypass. Having the correct power and the right EQ will make the AD sound its best. The amp can utalize balanced stereo euroblock, stereo unbalanced mini jack, or high level euroblock inputs.
Specifications
| UPC | 644216215201 |
|---|---|
| Manufacturer | SolidDrive |
| Manufacturer's Category | Amplifier |
| Depth | 4.9 in / 124.46 mm |
| Height | 1.2 in / 30.48 mm |
| Width/Diameter | 3.9 in / 99.06 mm |
| Shipping Weight | 3.1 lbs / 1.41 kg |
| Carton Height | 3.5 in / 88.9 mm |
| Carton Length | 10.25 in / 260.35 mm |
| Carton Width | 9.5 in / 241.3 mm |
| Certifications | CE, RoHS, UL60065, ETL-C/US, FCC |
| Enclosure Properties | Aluminum |
| Included Accessories | 3-Pin Euroblock, 4-Pin Euroblock, Mounting Hardware, Power Supply, Stereo RCA Adapter |
| TAA Compliant (Trade America) | No |
| BAA Compliant (Made in USA) | No |
| Input Impedance | 47K Ω Line Level, 600 Ω Balanced |
| Power Requirements | 32 v DC |
| Voltage Gain | 34 dB |
| Frequency Response (± 3 dB) | 20 Hz - 20 kHz |
