Product Description
Smoke Factory SF-0513 Radio Remote Control all Smoke Factory Machines
Overview
The SMOKE FACTORY Radio Remote Control is a radio remote control for all Smoke Factory devices with analogue input. The radio remote control is a UHF radio system consisting of a radio switch / hand transmitter and a receiver.
The fogging process can be started by pressing and holding the pre-programmed button 1 on the remote control. Only a short press of the key has no function. Releasing the button stops the fogging process.
Important: The pump value set on the machine is output.
The radio system operates on the two frequencies 433.62 MHz (frequency 1) or 434.22 MHz (frequency 2). By setting a jumper, the working frequency is determined. In the delivery state, frequency 1 is preselected as the operating frequency.
The radio switch can control a maximum of 4 channels. These four channels can be individual receivers or groups of receivers. Each channel can control an unlimited number of receivers.
In the delivery state, button 1 of the radio switch is coupled with the receiver. The wireless switch can therefore be used immediately without further configuration.
The radio remote control is designed for long ranges, approx. 100 m under optimal conditions. The wireless switch penetrates walls and even reinforced concrete. The visual contact of the radio switch and receiver is absolutely necessary for the maximum range.
Weight and dimensions
- Handheld transmitter: 41 g; 10 x 3.7 x 1.9 cm
- Receiver with antenna upright: 88 g; 12.5 x 3.1 x 9.5 cm
