Product Description
Shure SLXD4 Digital Wireless Receiver
The SLXD4 Receiver is the choice for confident presentation and performance - from lecture halls to live entertainment.
SLX-D Digital Wireless delivers transparent, 24-bit digital audio and rock solid RF performance with easy setup and rechargeability options in a suite of versatile wireless system configurations. Featuring industry-leading digital wireless technology and design, the SLXD4 easily syncs wireless transmitters. A variety of interchangeable microphone choices guarantees the right solution for a wide range of applications, from day-long presentations to nighttime performances.
Transparent Digital Sound, Dependable Performance, and More Mics
- The SLXD4 receiver is compatible with the SLXD1 bodypack and SLXD2 handheld transmitters.
- The system offers 24-bit digital audio with a fast transient response and over 120 dB of dynamic range—resulting in clear, accurate sound.
- The SLX-D operates in the G58: 470 to 514 MHz UHF band with a 44 MHz tuning range and 1760 selectable frequencies, far away from potential Wi-Fi interference in the 2.4 GHz band.
- Digital Predictive Switching Diversity uses a microprocessor to switch between the two antennas for the cleanest signal—before dropouts occur.
- Low latency makes the system ideal for applications that require live sound reinforcement.
- Spectrum-efficient digital transmission technology allows for up to 32 mics to be used at once.
- Up to 10 compatible systems per 6 MHz TV band and 12 systems per 8 MHz band are supported.
- Ethernet networking saves you time with coordinated group scanning between multiple receivers from a single location; TCPI command streams from third-party companies such as AMX and Crestron are also supported.
Ready to Rackmount, Easy to Use
- Housed in a tough, half-rack metal chassis with detachable antennas, the SLXD4 receiver is a great fit for A/V installations or as part of a portable rackmount rig—ready to travel to a meeting or event.
- The SLX-D is engineered to provide outstanding sound for small- to medium-sized spaces and facilities—without costly, complicated features required primarily for large venues.
- Intuitive front-panel controls and a high-contrast LCD screen with audio and RF meters makes set up a snap.
- The auto-scan function automatically seeks out the cleanest available frequency for you. The receiver and transmitter then easily link to the same frequency via infrared.
- The receiver offers up to 60 dB of adjustable gain, and the display shows you where the ideal level should be.
Enhance the Reliability of Your Receiver
- Adding UA874 active antennas or PA805SWB passive antennas increases the range of your system and offers increased protection against interference.
- The UA844+SWB antenna distribution system (available separately) lets you stretch the power of your antenna pairs, giving you more on-air channels in less setup time.
Features
- Transparent 24-bit digital audio
- Extended 20 Hz to 20 kHz frequency range (microphone dependent)
- 120 dB dynamic range
- Digital predictive switching diversity
- 44 MHz tuning bandwidth (region dependent)
- 32 available channels per frequency band (region dependent)
- Up to 10 compatible systems per 6MHz TV band; 12 systems per 8 MHz band
- Easy pairing of transmitters and receivers over IR scan and sync
- Up to 8 hours from 2 AA batteries or optional Shure SB903 rechargeable battery
- Interchangeable microphone capsules
- Rugged metal construction
System
|
Wireless Transmission |
Digital UHF |
|
Number of RF Channels |
1760 |
|
Diversity |
True Digital Diversity |
|
RF Frequency Band |
G58: |
|
RF Bandwidth |
44 MHz |
|
Frequency Step Size |
25 kHz |
|
RF Channel Scanning |
Auto-Scan |
|
Max Operating Range |
328' / 100 m |
|
Max Systems per Setup |
32 |
|
Latency |
3.2 ms |
Receiver
|
Form Factor |
Tabletop / Rackmount |
|
Mounting Options |
Rackmount (with Included Hardware) |
|
Rackmount Size |
1 RU (1/2 Rack) |
|
Antenna |
2 x 1/4 Wave External, BNC (Rear-Mount) |
|
Number of Audio Channels |
1 |
|
Audio I/O |
1 x XLR 3-Pin Male Balanced Mic/Line Output |
|
Gain Range |
0 to +21 dB (3 dB Steps) |
|
Pad |
30 dB |
|
Audio Output Level |
-18 to +42 dB (Balanced, Unbalanced) |
|
Phantom Power Protection |
On 1/4", XLR Outputs |
|
Frequency Response |
20 Hz to 20 kHz +1/-2 dB (Dependent on Mic) |
|
Network I/O |
1 x RJ45 (10/100 Mb/s) |
|
Network Protocols |
DHCP, Manual IP |
|
Impedance |
1/4" Output: |
|
Approximate RF Sensitivity |
-97 dBm |
|
Adjacent Channel Isolation |
>70 dB |
|
Spurious |
Rejection: >75 dB |
|
Power Requirements |
AC/DC Power Adapter |
|
AC/DC Power Adapter |
15 VDC at 600 mA, Center-Positive (Included) |
|
AC Input Power |
100 to 240 VAC, 50 / 60 Hz |
|
Display & Indicators |
LCD (AF Level, Channel, Frequency, Group, RF Level, Transmitter Battery Status) |
|
Housing |
Steel |
|
Operating Temperature |
0 to 122°F / -17 to 50°C |
|
Storage Temperature |
-20 to 165°F / -28 to 73°C |
|
Dimensions |
7.8 x 1.7 x 6" / 197 x 42 x 152 mm |
|
Weight |
1.8 lb / 816 g (without Antenna) |
