Product Description
Shure SLXD14 Wireless Guitar System with SLXD1 Bodypack Transmitter
The SLXD14 Wireless System delivers transparent, 24-bit digital audio and rock-solid RF performance for a wide range of applications, from day-long presentations to nighttime performances. Operate up to 32 compatible systems per 44 MHz band, with easy setup and optional rechargeability accessories for wireless excellence, wherever required. Ships with SLXD4 single-channel receiver, SLXD1 bodypack transmitters and WA305 Premium Instrument Cable with antenna and rackmount accessories and 2 AA batteries.
Lightweight Bodypack Transmitter with Premium Instrument Cable
- The 3' Shure WA305 is a straight 1/4" TS guitar cable with gold-plated Neutrik connectors.
- The cable is designed to reduce handing noise and plugs into the locking TA4M connector on the compact SLXD1 bodypack transmitter.
- The rugged, plastic transmitter has a belt clip that attaches to the talent’s clothing or guitar belt and an LCD that shows essential information.
Transparent Digital Sound, Dependable Performance, and More Channels
- The SLX-D delivers 24-bit digital audio with a fast transient response and over 120 dB of dynamic range—resulting in clear, accurate sound with detail and nuance.
- The system operates in the G58: 470 to 514 MHz UHF band with a 44 MHz tuning range and 1760 selectable frequencies, far away from potential Wi-Fi interference in the 2.4 GHz band.
- Digital Predictive Switching Diversity uses a microprocessor to switch between the two antennas before dropouts occur.
- A low latency of 3.2 ms makes the system ideal for applications that require live sound reinforcement.
- The SLX-D's spectrum-efficient digital transmission technology allows for up to 32 mics or instruments to be used at once.
- Up to 10 compatible systems per 6 MHz TV band and 12 systems per 8 MHz band are supported.
- Ethernet networking saves you time with coordinated group scanning between multiple receivers from a single location; TCPI command streams from third-party companies such as AMX and Crestron are also supported.
Ready to Rackmount, Easy to Use
- Housed in a tough, half-rack metal chassis with detachable antennas, the SLXD4 receiver is a great fit for installations or as part of a portable rackmount rig—ready to travel to a show or event.
- The SLX-D is engineered to provide outstanding sound for small- to medium-sized spaces and facilities—without costly, complicated features required primarily for large venues.
- Intuitive front-panel controls and a high-contrast LCD screen with audio and RF meters makes set up a snap.
- The auto-scan function automatically seeks out the cleanest available frequency for you. The receiver and transmitter then easily link to the same frequency via infrared.
- The receiver offers up to 60 dB of adjustable gain and the display shows you where the ideal level should be.
Optional Rechargeable Battery Management
- Adding the SB903 lithium-ion rechargeable battery, along with an SBC10-903 single charger or an SBC203 dual-docking charger, offers a cost-effective and environmentally friendly alternative to throwing away AA batteries (batteries and charger available separately).
- Using the SB903 battery and SBC203 charger simplifies the task of keeping multiple transmitters charged and ready—you can even recharge the battery while still in the transmitter.
- When powered by an SB903, the transmitter displays the remaining battery life in hours and minutes.
Enhance the Reliability of Your System
- Adding UA874 active antennas or PA805SWB passive antennas increases the range of your system and offers increased protection against interference.
- The UA844+SWB antenna distribution system (available separately) lets you stretch the power of your antenna pairs, giving you more on-air channels in less setup time.
A Variety of Mics and Transmitters Available
Shure offers numerous microphone options to adapt your SLX-D system as your needs evolve.
- The WB98H/C miniature condenser microphone clamps onto the bell of wind instruments or onto the rim of percussion instruments.
- The SM35 is a comfortable, durable headset microphone for active performance.
- The WL183 omnidirectional lavalier mic is a clip on mic that offers consistent pickup even when the talent turns away from the mic.
- The WL184 supercardioid lavalier mic offers a narrower, feedback-resistant pickup pattern for louder events.
- The SLXD2 handheld transmitter is available with several interchangeable mic capsule options including the KSM8 and the legendary SM58.
Included
- 1 - single channel receiver
- 1 - bodypack transmitter
- 1 - WA305 Premium Guitar/Bass Cable with locking thread
- 2 - AA batteries
- 2 - 1/4 wave antennas
- 2 - bulkhead adapters
- 2 - 22" BNC cables
- 1 - power supply
- 1 - black vinyl zippered bag
- 1 - rack mount bracket (short)
- 1 - rack mount bracket (long)
- 1 - linking plate
- 1 - hardware kit
- 1 - quick start guide
- 1 - warranty
- 4 - adhesive foot
Receiver
Transmitter
