Product Description

Shure QLXD2/N8CB Handheld Transmitter with Nexadyne 8/C Cardioid Microphone

Overview

Enjoy legendary audio quality, rock-solid wireless performance, and the freedom to roam with the QLXD2 handheld transmitter by Shure. Boasting 24-bit digital audio and efficient RF spectrum usage, the QLXD2 is your ticket to worry-free wireless performance in any venue. With a 100m (330 ft.) range, easy IR syncing, durable all-metal construction, and over 120 dB of dynamic range, the QLXD2 delivers clear, uninterrupted signals without the need for transmitter gain adjustment.

Featuring patented Shure Revonic™ dual-engine transducer technology, the Nexadyne 8/C Dynamic capsule features two precisely calibrated transducers working in perfect harmony to deliver optimal performance. Its exceptional cardioid polar pattern linearity and state-of-the-art acoustic signal processing ensure a natural, clean sound that easily reaches every corner of the venue.

Enjoy up to 9 hours of continuous use with AA batteries, or upgrade to the optional lithium ion rechargeable battery for up to 10 hours of runtime. With interchangeable Shure microphone capsules, 20 Hz to 20 kHz frequency range, and 1, 10 mW selectable RF output power, the QLXD2 transmitter offers exceptional flexibility and performance to fill your wireless audio needs.

Features

• 20 Hz to 20 kHz frequency range with flat response (actual response is microphone dependent)
• Interchangeable Shure microphone capsules, including the legendary SM58®
• AES 256-bit encryption for secure transmission
• Over 120 dB of dynamic range – no transmitter gain adjustment needed
• 1, 10 mW selectable RF output power
• Up to 9 hours continuous use with 2 x AA alkaline batteries
• Optional Shure SB900B lithium ion rechargeable battery provides up to 10 hours of continuous use and reports remaining runtime in hours and minutes
• External charging contacts for docked charging
• Backlit LCD with easy to navigate menu and controls
• Selectable display mode showing group/channel, frequency, or battery runtime
• 100 meter (330 ft.) line-of-sight operating range
• Rugged metal construction
• Frequency and power lockout

Includes

• 1 QLXD2/N8CB Handheld Wireless Microphone Transmitter
• 1 WA371 Mic Clip

Specifications

• Mic Offset Range: 0 to 21 dB (in 3 dB steps)
• Battery Type: Shure SB900A Rechargeable Li-Ion or AA batteries 1.5 V
• Battery Runtime @ 10 mW: Shure SB900A: up to 10 hours, Alkaline: up to 9 hours See Battery Runtime Chart
• Dimensions: 256 mm × 51 mm (10.1 in. × 2.0 in.) L × Dia.
• Weight: 347 g (12.2 oz.), without batteries
• Housing: Machined aluminum
• Audio Input
  • Configuration: Unbalanced
  • Maximum Input Level 1 kHz at 1% THD: 145 dB SPL (SM58), typical Note: Dependent on microphone type
• RF Output
  • Antenna Type: Integrated Single Band Helical
  • Occupied Bandwidth: < 200 kHz
  • Modulation Type: Shure proprietary digital
  • Power: 1 mW or 10 mW See Frequency Range and ouput power table, varies by region
