Product Description
Shure MX395W/C Microflex Low-Profile Cardioid Boundary Microphone for Installs (White) 3-Pin XLR
Key Features
- For Speech and Vocal Capture
- Low-Visibility Design
- Cardioid Polar Pattern
- Resists Cell Phone Interference
Overview
This white Shure MX395 Microflex is a cardioid boundary microphone designed to capture high-quality speech and voice for sound-reinforcement and teleconferencing installations in governmental, institutional, religious, and business settings.
The MX395 can be permanently installed on conference tables, desks, or lecterns using the included mounting hardware. Its low-profile design is only 1" in diameter and extends just 0.8" above the mounting surface, ideal for boardrooms and other sites where minimal mic visibility is of high priority and aesthetics are important.
This version of the MX395 features a cardioid polar pattern best used for a single person or two people sitting side by side. The mic takes advantage of the boundary effect to capture clear speech with reduced room ambience for intelligibility. A built-in, low-cut filter can be used to attenuate low-frequency table noise that can muddy your sound.
Designed with proprietary CommShield technology, the MX395 resists interference from devices such as cell phones and two-way communication devices.
The MX395 is equipped with a 3-pin XLR connector and requires 11 to 52V phantom to operate.
Specifications
Form Factor | Boundary/Surface Mount |
Sound Field | Mono |
Capsule | Electret Condenser |
Polar Pattern | Cardioid |
High-Pass Filter | 150 Hz, 6 dB/Octave |
Frequency Range | 50 Hz to 17 kHz |
Maximum SPL | 121 dB SPL |
Impedance | 170 Ohms |
Sensitivity | 18 mV/Pa |
Dynamic Range | 93 dB |
Signal-to-Noise Ratio | 66 dB |
Equivalent Noise Level | 28 dB A-Weighted |
THD | 1% |
CMRR | 45 dB |
Output Connectors (Analog) | 1 x XLR 3-Pin Male (on Mic) |
Operating Voltage | 11 to 52 V (Phantom Power) |
Operating Current Consumption | 2 mA |
Color | Black |
Mounting | Surface-Mount (with Included Hardware) |
Operating Temperature | 0 to 135°F / -17.8 to 57.2°C |
Operating Humidity | 0 to 95% |
Storage Temperature | -20 to 165°F / -28 to 73°C |
Dimensions | ø: 1.26H: 4.02" / ø: 32H: 102 mm |
Weight | 0.3 lb / 136 g |
