Product Description
Shure BLX1288/CVL BLX Series Dual-Channel Wireless Microphone System
The BLX1288/CVL Dual Channel Combo Wireless System is part of the BLX wireless systems family. Shure BLX Wireless Systems combine professional-quality sound with simple setup and an intuitive interface for legendary audio performance right out of the box. Precision-built and available in a variety of configurations, it’s the most accessible way to own the stage. Includes BLX88 dual-channel receiver, BLX1 bodypack transmitter, BLX2/PG58 handheld transmitter, CVL lavalier microphone, power supply, microphone clip, lavalier clip, lavalier windscreens, and user guide. Operates in the H10 frequency band.
Features
- For Two Presenters or Lecturers
- CVL Cardioid Lav Mic
- Lightweight Bodypack Transmitter
- PG58 Cardioid Mic/Transmitter
- BLX88 dual-channel receiver
- BLX1 bodypack transmitter
- BLX2/PG58 handheld transmitter
- CVL lavalier microphone
- Power supply
- Microphone clip
- Lavalier clip
- Lavalier windscreens
- 4 x AA batteries
- User guide
Specs
System
|
Wireless Transmission |
Analog UHF |
|
Number of RF Channels |
123 |
|
Included Transmitters |
1 x Bodypack |
|
Diversity |
Antenna Diversity |
|
RF Frequency Band |
J10: 584 to 608 MHz |
|
RF Bandwidth |
24 MHz |
|
RF Channel Scanning |
Auto-Scan |
|
Max Operating Range |
300' / 91.4 m (Line of Sight) |
|
Max Systems per Setup |
12 |
|
Dynamic Range |
100 dBA |
Receiver
|
Form Factor |
Tabletop |
|
Antenna |
2 x Internal, Fixed |
|
Number of Audio Channels |
2 |
|
Audio I/O |
2 x XLR 3-Pin Male Balanced Output |
|
Audio Output Level |
XLR Outputs: |
|
Frequency Response |
50 Hz to 15 kHz (Dependent on Mic) |
|
Impedance |
XLR Outputs: |
|
Approximate RF Sensitivity |
-105 dBm |
|
Power Requirements |
AC/DC Power Adapter |
|
AC/DC Power Adapter |
12 to 15 VDC at 160 mA, Center-Positive (Included) |
|
Display & Indicators |
1 x Multi-Segment LED (Channel, Group) |
|
Housing |
ABS |
|
Operating Temperature |
0 to 135°F / -17 to 57°C |
|
Dimensions |
15.3 x 1.6 x 4.6" / 388 x 40 x 116 mm |
|
Weight |
15.1 oz / 429 g |
Transmitter
|
Form Factor |
Bodypack |
|
RF Output Power |
10 mW |
|
Audio I/O |
1 x TA4/Mini XLR 4-Pin Male Input (Lockable) |
|
Muting |
Off/On Switch |
|
Auto-Level Control |
No |
|
Gain Range |
-16 to +10 dB |
|
Sync Method |
Manual |
|
Antenna |
1 x Flexible Whip, Fixed (Beltpack) |
|
Power Requirements |
Battery |
|
Battery Type |
2 x AA (Included) |
|
Approx. Battery Life |
14 Hours (Alkaline) |
|
Display & Indicators |
1 x Multi-Segment LED (Channel, Group) |
|
Housing |
ABS |
|
Dimensions |
2.5 x 4.3 x 0.8" / 64 x 110 x 21 mm |
|
Weight |
2.6 oz / 75 g (without Batteries) |
Microphone
|
Form Factor |
Lavalier |
|
Sound Field |
Mono |
|
Capsule |
Electret Condenser |
|
Polar Pattern |
Cardioid |
|
Frequency Range |
50 Hz to 20 kHz |
|
SNR |
72 dB |
|
Equivalent Noise Level |
22 dB |
|
Maximum SPL |
139 dB SPL |
|
Impedance |
600 Ohms |
|
Dynamic Range |
117 dB |
|
Output Connectors |
1 x TA4/Mini XLR 4-Pin Female (Lockable) |
|
Cable Length |
4.27' / 1.3 m |
|
Operating Voltage |
5 V |
|
Weight |
0.88 oz / 25 g |
Transmitter 2
|
Form Factor |
Handheld |
|
RF Output Power |
10 mW |
|
Audio I/O |
None |
|
Muting |
Off/On Switch |
|
Auto-Level Control |
No |
|
Gain Range |
-20 to -10 dB |
|
Sync Method |
Manual |
|
Antenna |
1 x Internal (Handheld) |
|
Power Requirements |
Battery |
|
Battery Type |
2 x AA (Included) |
|
Approx. Battery Life |
14 Hours (Alkaline) |
|
Display & Indicators |
1 x Multi-Segment LED (Channel, Group) |
|
Housing |
ABS |
|
Dimensions |
2.5 x 4.3 x 0.8" / 64 x 110 x 21 mm |
|
Weight |
7.7 oz / 218 g (without Batteries) |
Microphone 2
|
Form Factor |
Handheld Capsule |
|
Sound Field |
Mono |
|
Capsule |
Dynamic |
|
Polar Pattern |
Cardioid |
|
Frequency Range |
50 Hz to 16 kHz |
|
Sensitivity |
-55 dBV/Pa |
