Product Description
Shure AD610 ShowLink Access Point for Axient Wireless Systems - No Power Supply
The AD610 ShowLink access point enables real-time remote control of all ShowLink-enabled Axient transmitters, including both ADX and AXT series models. The access point allows comprehensive management of transmitter parameters from the receiver or Wireless Workbench using 2.4 GHz (IEEE 802.15.4) wireless communication. All parameter changes occur without interruption to the performer.
Multiple access points can extend the operational range or increase the number of transmitters supported on the ShowLink network. The access point features true diversity antenna inputs along with mounting points for ¼"-20 and M6 x 1.0 thread.
Features
- Wireless network connectivity between all linked transmitters and access points
- Enables real-time wireless remote control of up to 24 transmitters per access point
- ShowLink offers ability to adjust gain, change frequencies, mute signals, and more
- True Diversity antenna scheme maintains a robust link in the 2.4GHz frequency range
- Automatic channel selection scans the 2.4GHz range for the best channel. Scans can be saved for future analysis in Wireless Workbench
- Automatic frequency agility moves the network to the best available channel if single degrades
- High power option for extended range, accessible via Wireless Workbench (region-dependent)
- Compatible with Axient Digital ADX series and Axient analog systems
Included
- Wireless Microphone Clip
- 5/8" to 3/8" Thread Adapter
- Shielded 25' Ethernet Cable
- Power Supply
Specs
|
Antennas |
2 x Omnidirectional 2.4 GHz |
|
Capacity |
24 Axient ShowLink transmitters (AXT or ADX models) |
|
Network Type |
IEEE 802.15.4 |
|
Frequency Range |
2.40 to 2.4835 GHz (16 channels) |
|
RF Output Power |
10 dBm ERP / 20 dBm ERP |
|
Working Range |
500 to 1600' / 150 to 500 m |
|
Antenna Connector |
2 x SMA |
|
Antenna Impedance |
50 Ohms |
|
RF Sensitivity |
-106 dBm, typical (integrated antenna) |
|
Network Interface |
Ethernet 10/100 Mb/s |
|
Network Addressing Capability |
DHCP or manual IP address |
|
Mounting |
WA371 microphone clip or 1/4"-20 thread mount |
|
Power Requirement |
Power over Ethernet (PoE) Class 1: 36 to 57 VDC/VAC |
|
Certifications |
WEEE Directive 2002/96/EC, as amended by 2008/34/EC |
|
Housing |
Extruded aluminum |
|
Protection Rating |
IPX3 |
|
Operating Temperature |
0 to 140°F / -18 to 60°C |
|
Storage Temperature |
-20 to 165°F / -29 to 74°C |
|
Dimensions |
7.4 x 4.0 x 1.8" / 19.0 x 10.2 x 4.7 cm without antennas |
|
Weight |
16.3 oz / 464 g without antennas |
