Product Description
Shure AD4DNP Axient Digital Two-Channel Wireless Receiver - No Power Supply
The Shure AD4D-NP is a 2-channel wireless receiver housed in a rugged, single-rack unit, packaged without accessories for use as an additional receiver in an existing system. Part of the Axient Digital system, it delivers mission-critical signal stability and clear, transparent sound for professional productions that demand flawless execution.
Every feature has been stress-tested to enable seamless, uninterrupted audio in high-profile applications such as televised live performances, award shows and corporate events, the Broadway stage, secure government installations, and state-of-the-art meeting and training facilities.
The AD4D-NP operates in a single 166-MHz ultra wide bandwidth that encompasses the entire usable UHF range from 470 to 636 MHz. It offers low 2ms latency, XLR/AES3 + AES67/Dante outputs, and 256-bit encryption. The Dante Cue and Dante Browse features enable high-fidelity headphone monitoring from any connected Dante-enabled device.
In standard mode, Axient Digital supports over 120 simultaneous channels. For high channel counts, HD mode allows up to 47 active transmitters per 6 MHz TV channel. The receiver is compatible with AD1, ADX1, ADX1M, AD2, ADX2, and ADX2FD transmitters.
Features
- For Major Events, High-End Installations
- 2 x Digital Audio Channels, 1 Rackspace
- 166 MHz Ultra wide Tuning Range
- Expandable to 120+ Channels
- True Digital Diversity Reception
- 4 x Ethernet/Dante Ports
- XLR and AES3 Outputs
- RF Cascade Ports
- Secure AES-256 Encryption
Included
- Hardware Kit
- AC Power Jumper Cable
Specs
System
|
Wireless Transmission |
Digital UHF |
|
Number of RF Channels |
6640 |
|
Diversity |
True Digital Diversity |
|
RF Frequency Band |
A: 470 to 636 MHz |
|
RF Bandwidth |
166 MHz |
|
Frequency Step Size |
25 kHz |
|
Max Operating Range |
328.1' / 100 m |
|
Max Systems per Setup |
120 |
|
Latency |
2 to 2.9 ms (Selectable) |
|
Modulation |
Proprietary |
Receiver
<td style="width: 207.0pt; border: solid windowtext 1.0pt; border-top:|
Form Factor |
Rackmount |
|
Mounting Options |
Rackmount (with Included Hardware) |
|
Rackmount Size |
1 RU (Full Rack) |
|
Antenna Bias Voltage |
12 to 13 VDC, 150 mA (per Antenna) |
|
Number of Audio Channels |
2 |
|
Audio I/O |
2 x XLR 3-Pin Male Balanced Output |
|
Gain Range |
-18 to +42 dB (1 dB Steps) |
|
Pad |
30 dB |
|
Audio Output Level |
XLR Outputs: |
|
Frequency Response |
20 Hz to 20 kHz ±1 dB (Dependent on Mic) |
|
Network I/O |
4 x RJ45 (1 Gb/s) |
|
Network Protocols |
DHCP, Dante, Manual IP |
|
Word Clock I/O |
1 x BNC Input |
|
Impedance |
XLR Outputs: |
|
Approximate RF Sensitivity |
-98 dBm |
|
Adjacent Channel Isolation |
>70 dB |
|
Spurious |
Rejection: >80 dB |
|
Power Requirements |
AC Input |
