    • Sennheiser XSW 1-ME3-A UHF Headmic Set (A: 548 to 572 MHz)

    MSRP: $479.00
    Was: $399.00
    Now: $349.00
    (You save $130.00 )
    SKU:
    XSW 1-ME3-A
    UPC:
    615104278363
    Availability:
    Typically ships in 3-5 business days.
    Shipping:
    Calculated at Checkout
    Adding to cart… category.add_cart_announcement

    Product Description

    Sennheiser XSW 1-ME3-A UHF Headmic Set (A: 548 to 572 MHz)

    Overview

    The XSW 1-ME3-A UHF Headmic Set from Sennheiser is an easy to use all-in-one wireless system for singers and presenters. It can be used to keep your hands free and capture audio for live sound applications and performers who dance and sing.

    The set includes an intuitive stationary receiver for quick set-up and hassle-free handling, as well as a lightweight bodypack transmitter and a headset microphone. It is built with antenna-switching diversity reception and features automatic frequency management and synchronization via remote channel. Up to 10 compatible channels are available. Additionally, an AC power adapter and two AA batteries are also included.

    Features

    • Featuring Sennheiser's evolution ME 3-II headmic
    • Selectable UHF frequencies within a large bandwidth
    • Up to 10 compatible channels
    • Diversity reception

    Includes

    • (1) EM XSW 1
    • (1) SK XSW
    • (1) ME 3-II lavalier headmic (cardioid, condenser)
    • (1) NT 12-5 CW

    Specifications

    System
    Modulation
    Wideband FM
    Frequency Range
    A: 548 to 572 MHz
    Switching Bandwidth
    Up to 24 MHz
    Signal to Noise Ratio
    ≥ 103 dBA
    Total Harmonic Distortion
    ≤ 0.9%
    Temperature Range
    Operation: 32 to 104°F (0 to +40°C)
    Storage
    -4 to 158°F (-20 to 70°C)
    Transmitter Synchronization
    2.4 GHz, Low Power OQPSK (only active during synchronization)
    Receiver
    Principle
    Double superheterodyne
    Diversity
    Antenna switching diversity via internal antennas
    Sensitivity
    < 3 μV at 52 dBA RMS S/N (at peak deviation)
    Frequency Response
    50 Hz to 16 kHz (-3 dB)
    Max Output Voltage
    At Peak Deviation, 1 kHz AF
    1/4" (6.3 mm) Jack Socket (unbalanced): +6 dBu
    XLR Socket (balanced): +12 dBu
    Adjustment Range
    Audio: 45 dB, adjustable in 5-dB steps
    Power Supply
    12 VDC nominal, 300 mA
    Squelch
    Adjustable from 3 dBμV to 28 dBμV (combined with pilot tone)
    Line/Mic Level
    20 dB, switchable
    Material of Construction
    ABS housing
    Dimensions
    7.9 x 1.7 x 5.0" (200 x 42 x 127 mm)
    Weight
    12 oz (340 g)
    Bodypack Transmitter
    Output Power
    10 mW
    Frequency Response
    Line: 50 Hz to 16 kHz
    Mic: 50 Hz to 16 kHz
    Audio Input
    1/8" (3.5 mm) jack socket
    Input Voltage
    Mic/Line at 3% THD: Typ. 1.V RMS mic / typ. 2.6 V RMS line at -30 dB gain
    Power Supply
    2 x AA batteries, 1.5 V
    Operating Time
    Approximately 10 hours
    Adjustment Range
    Transmitter Sensitivity: 0 to -30 dB, adjustable in 10 dB steps
    Material of Construction
    Rugged ABS housing
    Dimensions
    2.8 x 3.8 x 1.1" (71 x 96 x 28 mm)
    Weight
    3.4 oz (95 g)
    Headset
    Microphone Type
    Condenser, pre-polarized
    Sensitivity
    1.6 mV/Pa
    Polar Pattern
    Cardioid
    Max SPL
    150 dB

    Other Details

    This limited product warranty is Sonova Consumer Hearing’s only warranty and the customer's only remedy concerning the product. All other representations, warranties or conditions, expressed or implied, written or oral, including but not limited to any warranties or guarantees of merchantability, fitness for a particular purpose, or non-infringement, are expressly excluded. As a result, except as set forth in the previous and following paragraphs, the product is sold "as-is" and the customer assumes the entire risk as to the product's suitability for their needs, its quality and its performance. Sennheiser-branded consumer hearing products: 2 years from original purchase Wired Evolution Products: 10 Years Neumann Products: 1 Year Refurbished products: Carry the standard warranty** ** Remanufactured product warranties are only valid when purchased from an authorized Sennheiser reseller and only apply to Sennheiser-branded consumer hearing products. Excludes any remanufactured Headphone, TeleCom Headset, or Bluetooth® product, which carry a 90-day warranty. Out of warranty TeleCom headset replacements have a 1 year warranty.
