Product Description

Sennheiser EW-D ME3 SET Digital Wireless System with ME3 Headset Microphone

Overview

For over 20 years Sennheiser's Evolution Wireless has allowed performers of every type to roam free. The next logical step in that Evolution is the EW-D series, delivered just when we need to roam more than ever!

The EW-D-ME3 is a receiver and bodypack set with a Sennheiser ME3 lavalier mic that delivers pure digital wireless audio free from noise, interference, and annoying static bursts. The system's automated setup makes for quick easy implementation with little effort. A dedicated mobile app eschews deep menus giving users a convenient familiar way to operate and change settings.

The ME3 head-worn mic has a cardioid pickup pattern that rejects sound from the rear and sides to deliver intimate highly intelligible vocals. Whether speaking or singing, they'll be hanging on every word.

With over 2,200 selectable frequencies you're never out of range or out of touch. Speaking of range, the EW-D-ME3's 134 dB dynamic range means they'll hear everything you intend, from a whisper to a scream. The bodypack's familiar metal housing reflects Sennheiser's standard rugged design. Operating up to 12 hours per charge when used with the Li-ion battery pack (sold separately) or 8 hours on a pair of AA batteries, you can be sure the show will go on, and on!

Includes

• EW-D EM rack receiver
• EW-D SK bodypack transmitter
• ME 3 headset microphone
• 2 rod antennas
• Power supply with country adapters
• Rackmount set
• 4 rubber feet
• Quick guide
• Safety guide
• Manufacturer declaration sheet

Features

• Digital wireless eliminates noise, interference and static bursts
• UHF transmission greatly enhances range, reliability and scalability
• Mobile App streamlines setup and operation and eliminates complicated menus
• Automated setup creates reliable connections with minimal time and effort
• Up to 2,240 selectable frequencies
• Lithium Ion battery pack delivers up to 12 hours of operation (up to 8 hours of operation with AA batteries)
• 56 MHz Bandwidth will allow for up to 90 channels
• Preserves every detail of even the most dynamic performances with 134 dB transmitter dynamic range

Specifications

• Audio link frequency ranges
  • Q1-6: 470.2 - 526 MHz
  • R1-6: 520 - 576 MHz
  • R4-9: 552 - 607.8 MHz
• Bluetooth® Low Energy frequency range: 2402 - 2480 MHz
• Audio frequency response: 20 Hz - 20 kHz (-3 dB) @ 3 dBfs
• Audio THD: ≤ -60 dB for 1 kHz @ -3 dBfs input level
• Operating temperature -10 °C - +55 °C (14 °F - 131 °F)
• Relative humidity 5 - 95 % (non-condensing)
• EW-D EM (Rack Receiver)
  • Input voltage: 11 - 13 V ⎓
  • Input current: ≤ 300 mA
  • Transmit power (radiated): BLE: max. 10 mW EIRP
  • Audio output power: 18 dBu max.
  • Dimensions: 212 x 44 x 189 mm
  • Weight: approx. 1000 g (without antennas and power supply)
  • EW-D SK (Bodypack Transmitter)
  • Input voltage: 2.0 - 4.35 V
  • Input current: < 300 mA
  • Power supply: 2 AA batteries 1.5 V (alkali manganese) or BA 70
  • rechargeable battery pack
  • Occupied bandwidth: 200 kHz
  • Transmit power: (radiated) Audio link: 10 mW ERP (Range Y1-3: 12 mW ERP)
  • BLE: max. 10 mW EIRP
  • Dimensions: 63 x 80 x 20 mm (without antenna)
  • Weight: (without batteries) approx. 120 g
• ME3 Headset Microphone
  • Transducer principle: pre-polarized condensor microphone
  • Sensitivity: 1.6 mV/Pa
  • Sound pressure level: 150 dB SPL
  • Pick-up pattern: cardioid
  • Connector: 3.5 mm jack
  • Cable length: approx. 1.60 m
  • Temperature range: -10 °C to +55 °C
