Product Description
Roxx 12402301 B.FLEX Black
Amazingly versatile, incredibly stylish – that is what the FLEX Series is all about.
The B.FLEX is a battery driven, dual light source fixture for professional use in indoor and outdoor applications such as wall washer, spotlight, deco-effect light and many more. The very narrow beam lens from centric LED, in combination with various filters and the single pixel controllable HALO EFX ring gives room for unlimited creativity.
1 ROXX® dual-bayonet system
Due to our special designed dual-bayonet system all our one-size accessories like holographic filters, glare-shields or creative adaptors such as FLEX Light Tubes and HAT can be combined and fit tool-free to all FLEX models.
2 Halo EFX engine
One central high-power LED, in combination with twenty-four ultra-bright SMD LEDs create amazing, bi-color effects in wall-wash and deco-light applications. Due to its single pixel control, ROXX HALO EFX engine allows advanced and creative effect possibilities and a stunning eye-candy look. The versatile tool for wall-wash, bi-color, eye-candy effects and light tubes.
The individual LED´s can be controlled by any DMX source, or by using our internal preprogrammed Macro patterns and chasers.
3 Light Tubes
The 6 different sized, white light tubes can be attached to the FLEX series, creating stunning deco effects. Combining the two light sources will create spectacular fading colors or fire effects, due to the different radiation angles.
Also, the combination of different tube lengths allows lighting designers a lot of creativity.
4 FLEX HAT
The perfect accessory for Gala dinner table or glare free outdoor light applications. Due to it´s special designed reflector the light- throwing diameter reaches around 2m, ideal for table illumination while showing a nice deco effect at the same time, due to the mix between reflections and shadings.
6 Diffusors & Batwing
Thanks to the inner bayonet, filters can be changes easily, from native 3° to circular 5°, 10°, 20°, and elliptical 5°x20° or 5°x30°.
7 Ingenious 2in1, fan-free cooling system for a clean and unique design
The specially designed Copper Heat pipe cooling system of the FLEX Series is a highly thermally conductive heat pipe with a special capillary structure and liquid inside. The liquid quickly absorbs the heat generated by the LED, heats up and migrates in vapor form to the other end of the heat pipe, where it cools down again due to the low temperature prevailing there and thus condenses. This continuous cycle creates a kind of water cooling, which gives the FLEX Series a silent and at the same time very effective and efficient heat dissipation.
8 Battery Operated for 100% Flexibility
Long-life, powerful lithium-ion battery guarantees reliable operation up to 24 hours runtime and 100% flexibility on any event. The integrated Battery Management System prevents overcharging and exhaustive discharge. An additional charging setup protects the battery during longer storage and thus ensures a longer service life.
SPECIFICATIONS
Photometrics
| LED expected lifetime | 50.000 hours |
| Lightsource | 1x40W RGBL |
| Type of optical system | Total Internal Reflection lens (TIR) |
| LED PWM Frequency | selectable 800Hz, 1.200Hz, 2.000Hz, 3.600Hz, 12kHz, 25kHz |
| Beam angles (50%) | 2,7° (native) |
| 4,8° (with 5° Filter) | |
| 10,1° (with 10° Filter) | |
| 21,3° (with 20° Filter) | |
| 5,1° / 18,5° (with elliptical Filter 5°x20°) | |
| 5,9° / 21,7° (with elliptical Filter 5°x30°) | |
| Maximum Field angles (10%) | 4,2° (native) |
| 9,1° (with 5° Filter) | |
| 21,5° (with 10° Filter) | |
| 42,3° (with 20° Filter) | |
| 12,1° / 31,3° (with elliptical Filter 5°x20°) | |
| 20,6° / 42,1° (with elliptical Filter 5°x30°) | |
| Color temperature range | 2.000K – 10.000K |
| CRI / Ra | 88 |
| TLCI | 75 |
| Efficancy (max) | 25,22 lm/W |
| Luminous flux | 1.085 lm |
| illuminance Lux @ 3m (2,7° native) | 10.700lx |
| illuminance Lux @ 3m (with 5° Filter) | 2410lx |
| illuminance Lux @ 3m (with 10° Filter) | 625lx |
| illuminance Lux @ 3m (with 20° Filter) | 150lx |
| illuminance Lux @ 3m (with elliptical Filter 5°x20°) | 700lx |
| illuminance Lux @ 3m ((with elliptical Filter 5°x30°) | 445lx |
Dimensions & Weight
| IP class | IP65 |
| Body material | Aluminum, Nylon |
| Lens material | Tempered glass front |
| Net dimensions (w x h x d) |
120 x 200 x 120mm |
| Net dimensions inches | 4,72 x 7,87 x 4,72 inches |
| Physical Head Straigt Up Height (without Yoke) | 200mm (7,87 inches) |
| Physical Head Straight Up Height (including optional Yoke) | 250mm (9,84 inches) |
| Net weight (without Yoke) | 2,49 kg (5,49lbs) |
| Net weight (including optional Yoke) | 2,85 kg (6,28lbs) |
Electrical Data
| Operating Voltage | 100 – 240V 50/60Hz |
| Max power consumption | 62W |
| Input Voltage | 31V |
| Battery | 223,11Wh / Lithium-Ionen including BMS |
| Lifetime | 70% after 300 cycles |
| Battery Run Time | Up to 24 hours |
| Standby power | 6,7W |
| Charging Time (nominal) | 5h |
Operator & Controller
| DMX Functions | Dimmer Center, Dimmer Fine Center, Dimmer Halo, Dimmer Backlight Halo, Shutter Center, Shutter Halo, Shutter Backlight Halo, Duration Shutter Center, Red Center, Red Fine Center, Green Center, Green Fine Center, Blue Center, Blue Fine Center, Lime Center, Lime Fine Center, Red Halo, Green Halo, Blue Halo, Red Backlight Halo, Green Backlight Halo, Blue Backlight Halo, CTC Center , CTC Halo, CTC Backlight Halo, Color Macro Center, Color Macro Crossfade Center, Color Macro Halo, Color Macro Crossfade Halo, Color Macro Backlight Halo, Color Macro Crossfade Backlight Halo, Effect Pattern, Effect Pattern Speed, Effect Pattern Transition, Pixel RGB 1-24, Device Settings |
| DMX channels | 3CH CCT, 8CH COLOR MACRO, 6/9/10/17/21CH RGB, 7/11/18/23CH DIRECT, 28/29CH PATTERN, 80CH PIXEL |
| DMX modes | 14 |
| Protocol | CRMX, W-DMX™ G2, W-DMX™ G3, W-DMX™ G4, W-DMX™ G4S |
| USITT DMX512A | |
| RDM ANSI E1.20 | |
| Bluetooth Low Energy (BLE) | |
| Setting and addressing | OLED graphical display / 4 controls |
| RDM ANSI E1.20 | |
| Standalone mode | Auto Program, Editor, Color Macro, Quick Color, Tunable White, User Color, Timer |
| Wireless DMX | Lumenradio with RDM (CRMX) |
| indicator | OLED graphical display |
| controls | 4 touch sensitive, backlighted controls |
| Strobe | 0-20Hz |
| DMX I/O | IP65 Neutrik DMX socket |
| Power I/O | Low-voltage socket for external power supply |
Installation
| Mounting point | 1x centric M4, optional M4/1/4″ adapter for multifunctional clamps |
| Mounting point by optional Yoke | centric 13mm / 1/2″ hole |
| Orientation | Any |
| Rigging possibilities | Hanging or ceiling / pendant mount |
| Safety features | rear mount for safety wire |
| Minimum distance from flammable materials | 0,3 meters (11,8 inch) |
Thermal Characteristics
| Cooling | Combination of heatpipe & convection cooling |
| Humidity (max.) | 95% |
| Temperature range, Operating on Battery | -20°C to 40°C |
| Temperature range, Start-Up on Battery | -20°C to 40°C |
| Temperature range, Operating on DC Power Supply | 0°C to 40°C |
| Temperature range, Start-Up on DC Power Supply | 0°C to 40°C |
| Temperature range, Storage | -10°C to 25°C |
| Temperature range, Charging | 0°C to 40°C |
| Thermal Protection | Automatic overtemperature protection |
Compliance
| CE – 2014/30/EU: EMC Directive |
| EN 55103-2 |
| EN 55015 |
| EN 61547 |
| EN 61000-3-2 |
| EN 61000-3-3 |
| EN 55032 |
| CE – 2014/35/EU: Low Voltage Directive |
| EN 60598-1 |
| EN 60598-2-17 |
| EN 62471 |
| EN 60529 |
| RoHS2 Directive |
| 2011/65/EU |
| ETL C/US |
| FCC |
| UKCA |
