Rosco Image Spot UV Projector - IP65, DMX, Black, No Lens; Part #296000021657
Overview
Create textured UV lighting effects with the Image Spot UV LED projector. Using a mere 45W of power, the Image Spot UV packs an amazing amount of output into a versatile and compact design. The UV emitters, when combined with Image Spot’s crystal clear optics, vividly energize fluorescent objects or scenery from up to 40 feet (12m) away!
Image Spot UV has an IP65 rating, enabling it for use in both indoor and outdoor environments. Please note that Image Spot UV does not ship with a lens. Choose from the available narrow, medium and wide Lens Optic Accessories when ordering to achieve the imaging or beam spread your project requires.
Powerful 9,000 mW UV Output
The ultraviolet emitters inside the Image Spot UV provide enough UV output to project its beam up to 40 feet (12m). The fixture also features a dichroic glass, UV-Pass filter that eliminates visible light output, while allowing an abundant amount of UV energy to pass.
Accepts Image Spot Gobos
Perfect for projecting textures and patterns onto fluorescent scenery, the Image Spot UV is ready to accept Steel or Black & White Glass Gobos. Choose any Rosco design from the world’s largest library of standard gobo patterns, or project a custom gobo with a specific image, logo or “hidden message.”
Crystal Clear Optics
Image Spot's engineered optics produce a light beam with the highest uniformity and resolution, which enables the fixture to project even illumination or a crisp gobo image at distances up to 40 feet (12m).
Designed For Indoor And Outdoor Environments
Featuring an IP65 rating, the Image Spot UV allows designers to create fluorescent projection effects for indoor installations such as dark rides, nightclubs and museums, as well as outdoor venues such as haunts and theme park attractions.
Manual or DMX Controls
Control the output of the Image Spot UV using its on-board dimming controls or by connecting the fixture to a DMX control device for remote intensity control via a factory-installed, exterior-rated Cat5 cable.
What’s In The Box:
- Image Spot UV LED Projector
- Dichroic Glass UV-Pass Filter (Pre-Installed Inside The Gobo Cassette)
- Manual
- Image Spot Welcome Pack
Specifications
Input Voltage: 100-240VAC
Power Consumption: 45 Watts at maximum output
Output: 9,000 mW
Peak Wavelength:
- LED Emitters (without dichroic): 385 nm
- With included dichroic UV Pass filter: 365 nm
Lumen Maintenance: 20,000 hours at 25°C (LM-79-08)
Power Connection: 6.5 ft (2m) insulated cable, unterminated (connector not included)
Data: DMX512 In/Out via a factory-installed, 2m, exterior-rated Cat5e Cable/Gland
DMX Addressing: Rosco Programming Software
- www.rosco.com/imagespot/software
- USB to RS485 Programming Cable (IP65)
Dimensions: 7.8in x 4.8in x 6.8in (198mm x 123mm x 172mm) (including yoke)
Weight: 5.5 lbs (2.5 kg)
Operating Temperature: -13° to 104° F (-25° to 40° C)
Humidity: 0 - 95% non-condensing
Housing: Anodized Aluminum Extrusion
