Rolls MX42 Stereo 4 Channel Mixer RCA Passive
Description
The MX42 is a four channel stereo passive mixer. The unit mixes up to four stereo RCA signals such as CD, audio players even computers. All signals are mixed via stereo 100K ohm potentiometers to stereo RCA output connectors. The unit is passive, requiring no power.
Specifications
-
- Input Impedance:
- Mic: 10K Ohms XLR balanced
- Limiter Threshold: -5 dB to off, fully clockwise: No Limiting
- Setup Frequency: 1 kHz
- Slate Frequency: 20 Hz
- Output Attenuator: -30 dB
- Self Noise: -57 dB maximum, -90 dB typical
- Max Gain: +65 db
- S/N Ratio: 115 dB
- Frequency Response: 20 Hz - 30 kHz | +0, -3 dB
- Low Cut: 100 Hz
- Trim Range: 0 to + 38 dB
- Max Input: 0 dBV
- Current Draw: 45 mA with no Phantom Power or Signal.
- Phantom Power: +48 VDC
- Connectors: 4: Female XLR, 2: Male XLR, 3: 1/4", 1: 1/8" (3.5mm), 1 Center Negative power jack.
- Power: 12VDC / 200 mA
- Size: 9.5" W x 7.25" D x 2.375" H
- Weight: 4 lbs
- Four servo-balanced XLR Inputs.
- Two transformer-balanced XLR Outputs
- # Switchable Output Level ( Line level, or -30 dB pad)
- 1/4" TRS Stereo Monitor Input and Auxiliary Input.
- Switchable 48 Volt Phantom Power for each input.
- Switchable 100 Hz Low Cut filters for each input.
- # Main and Back-up battery compartments, never lose power.
- Level and Pan controls for each channel.
- Built in Limiter with variable Threshold control.
- 20 Hz Slate tone with Slate Microphone included.
- Switchable 1 kHz setup Tone.
- Calibrated VU meters.
- 1/4" and 3.5mm Headphone/Earphone Outputs with selectable Source Input (Main mix or Monitor input),and Level control.
- Rolls PS27 external power supply included.
