Product Description
RDL ST-EQ3 3 Band Equalizer - Line Level
Overview
The ST-EQ3 is a miniature wall and surface mount three-band equalizer from RDL that features a balanced bridging input, which may be connected unbalanced if desired. The output driver is 150 Ω balanced, and is intended to drive unbalanced or balanced lines of 150 Ω or higher impedance.
Equalization is accomplished by three active circuits, each controlling a separate audio band. These bands were carefully selected to yield a module that works effectively in a wide variety of systems. Setup of the ST-EQ3 is assisted by a peak overload LED which indicates excessive pre or post EQ levels.
Features
- 3-Band Audio Equalization
- Custom Tailored Audio Bandwidth
- Adjust To Pass Voice-Band Audio
- Adjust To Produce Smile-Curve for Music
- Low Noise and Low Distortion Equalization
Specifications
| Filter Type | Shelving |
| Number of Channels | Single |
| Inputs | Screw terminal |
| Outputs | Screw terminal |
| Maximum Input Level | Not specified by manufacturer |
| Frequency Bands | Low Band: 80Hz center Mid Band: 1kHz center High Band: 30kHz center |
| Bandwidth | Low Band: 20Hz to 300Hz Mid Band: 200Hz to 7kHz High Band: 3kHz to 30kHz |
| Range (Boost/Cut) | +/-12dB |
| Maximum Output Level | Not specified by manufacturer |
| Frequency Response | 20Hz to 22kHz, +/-0.5dB (EQ set flat) |
| Dynamic Range | Not specified by manufacturer |
| Noise | <-80dB below +4dBu |
| Dimensions | Not specified by manufacturer |
| Specialties | Requires ground-referenced, 24 to 33Vdc @ 25mA power source |
