Product Description
RDL EZ-VDA3B 1x3 Composite Distribution Amplifier (BNC)
Overview
The EZ-VDA3B is a composite video distribution amplifier with three outputs. The input and outputs are all 75 Ω on BNC connectors. If the outputs are connected to long coaxial cables (typically 100 to 1000 feet) the front-panel gain and equalization trimmers may be adjusted to restore picture clarity. The wide amplifier bandwidth supports high quality video distribution. The EZ-VDA3B is used in stores, houses of worship, restaurants, clubs, security and commercial sound systems.
Power Supply Included
- PS-24AS (USA)
- PS-24AX (International)
Features
- Composite Input to Three Composite Outputs
- Front-Panel GAIN and EQ Trimmers
- Operation with NTSC or PAL Signals
- 75 Ω Terminated Input
- Input and Outputs on Gold-Plated BNC Jacks
- Wide Bandwidth > 400 MHz
Advantages
- Gold Plated Professional BNC Jacks
- Wide Bandwidth Supports High Quality Video
- Exceptional Performance in a Small Amplifier
Specifications
Input: 75 Ω on BNC
Input level: 1 V p-p nominal
Gain: Unity to +6 dB (adjustable)
Bandwidth: > 400 MHz
Coupling: AC
Differential Gain: < 0.1%
Differential Phase: < 0.1 degree
Equalization: Flat to +7 dB @ 50 MHz (adjustable)
Residual Noise: < -90 dB (referenced to 1 V p-p)
Outputs (3): 75 Ω source-terminated on BNC jacks, 1 V p-p nominal (terminated)
24 Vdc power supply current: 20 mA (idle), 35 mA (max.)
