Product Description
RDL EZ-SX4 Stereo Audio Input Switcher - 4X1
Overview
The EZ-SX4 is a stereo audio source selector with an output volume control that adjusts the line-level output. This unit is ideal as a four input source selector feeding an associated audio amplifier. The user can conveniently select an audio source and adjust the level on the front panel. The EZ-SX4 is used in stores, houses of worship, restaurants, clubs, home component systems and commercial sound systems.
Power Supply Included
- PS-24AS (USA)
- PS-24AX (International)
Features
- Four Input Source Selection
- Unbalanced Stereo Audio Inputs and Output
- Inputs and Line Output on Rear-Panel RCA Jacks
- Line Output Level Controlled by Front-Panel Knob
- Full-Size Interlocking Pushbuttons on Front Panel
Advantages
- Easy-to-Push Large Buttons
- Solid-State Audio Switching
- Switch Noise Cannot Affect Signal Quality
- Select Source and Set Volume at One Location
- Connect Directly to a Power Amp as the User Interface
- Gold Plated RCA Input and Output Jacks
Specifications
Inputs (4): Stereo on dual RCA jacks, > 10 kΩ, -10 dBV nominal, +10 dBV max.
LEVEL control: Off to +12 dB gain
Output: Stereo on dual RCA jacks, line level, -10 dBV nominal, +17 dBV max.
Frequency Response: 10 Hz to 20 kHz (±0.01 dB)
THD+N: < 0.02%
Crosstalk: < -70 dB (1 kHz)
Noise: < -80 dB (below -10 dBV)
24 Vdc power supply current: 30 mA (idle), 60 mA (max.)
Case dimensions: 5.75” (14.6 cm)W x 5” (12.7 cm)D
Mounting size: 1/3 rack width
