Product Description
RDL EZ-MX4ML Mic and Stereo Line Audio Mixer - 4X1
Overview
The EZ-MX4ML is a stereo audio mixer with two mic and two line inputs. Microphones connect through balanced XLR jacks that provide phantom voltage. Both line inputs connect through RCA jacks; one also includes a MINI-jack input. Left and right channel LED VU metering facilitates easy level adjustment. The EZ-MX4ML is used in houses of worship, restaurants, clubs, meeting rooms, studios, broadcast and commercial sound systems.
Power Supply Included
- PS-24AS (USA)
- PS-24AX (International)
Features:
- Four Input Mixer, Two Mic and Two Line Inputs
- Two Balanced Microphone Inputs on XLR
- One Unbalanced Line Input on RCA Jacks
- One Line Input on MINI or RCA Jacks
- Unbalanced Output on RCA Jacks
- Microphone Inputs Provide Phantom Voltage
- Dual-LED VU Meter for Each Channel
Advantages:
- Optimized for Dynamic or Condenser Mics
- Headroom Accomodates High Input Levels
- Mic Headroom Increases at Lower Gain Settings
- Gold Plated RCA Input and Output Jacks
Specifications
Input Connections | 2 x Balanced XLR microphone inputs 4 x Unbalanced RCA inputs (2 stereo pairs) 1 x Unbalanced 3.5 mm stereo input, phone type |
Output Connectors | 2 x Unbalanced RCA outputs (stereo pair) |
Max Input/Output Gain | Mic Inputs: -11 dBu max Line Inputs: -10 dBV nominal on RCA jacks or Mini jack, +20 dBV max Output: -10 dBV nominal, +16 dBV max |
Impedance | Mic Inputs: 1.2 kOhms Line Inputs: > 10 kOhms |
Frequency Response | 80 Hz to 40 kHz (±1 dB, mic input, -6 dB at 20 Hz with integral high-pass filter) 10 Hz to 20 kHz (±0.01 dB, line input) |
THD & Noise | < 0.1% (20 Hz to 20 kHz, -50 dBu mic input) < 0.05% (20 Hz to 20 kHz, line input) |
Crosstalk | < -72 dB (1 kHz) |
CMRR | > -55 dB (20 to 20 kHz, mic input) |
Meter | Dual-LED VU Meter for Left and Right, calibrated to -10 dBV output |
Phantom Power | 24 V (IEC 61938:2013) |
Noise | < -65 dB (below -10 dBV output, -50 dBu mic input) < -75 dB (below -10 dBV output, line input) |
Mounting Size | 1 RU, 1/3 rack width |
AC Power Requirements | 24 VDC power supply current |
Current Draw | 50 mA (idle), 80 mA (maximum), 100 mA (maximum with phantom) |
Dimensions | 5.8 x 3.0" / 14.6 x 7.6 cm |
Weight | 0.6 lb / 0.3 kg |
