Product Description
RDL EZ-MPA2 Dual Microphone Preamplifier - Stereo Output with Compressors
Overview
The EZ-MPA2 is a stereo microphone preamplifier with front-panel volume controls and audio level metering. A front-panel switch engages audio compressors to control overloads and clipping during high level audio bursts or peaks from the microphones. Dynamic or condenser microphones are both supported with rear-panel switchable phantom voltage. The line output is available on RCA or MINI jacks. Left and right channel LED VU metering facilitates easy level adjustment. The EZ-MPA2 is ideal to add microphone inputs to mixers and amplifiers with line inputs. It is used in houses of worship, restaurants, clubs, meeting rooms, educational facilities, conference rooms, studios and commercial sound systems.
Power Supply Included
- PS-24AS (USA)
- PS-24AX (International)
Features
- Left and Right Balanced XLR Microphone Inputs
- Switch-Selectable Phantom on Rear Panel
- Unbalanced Output on MINI or RCA Jacks
- Input and Output Connections on Rear Panel
- Front-Panel Compressor Enable/Disable Switch
- Audio Compressors Control Overloads
- Front-Panel LEVEL Control for Each Channel
- Dual-LED VU Meter for Each Channel
Advantages
- Optimized for Dynamic or Condenser Mics
- Headroom Accomodates High Input Levels
- Headroom Increases with Lower Gain Settings
- Compressor Limits Clipping Over Wide Dynamic Range
Specifications
Number of Channels | 2 |
Inputs | 2 x XLR |
Output | 2 x RCA phono 1 x 1/8" stereo mini |
Phantom Power | +24V |
Multi Function | Compressor |
Gain Range | 0dB to +50dB |
Maximum Output Level | +16dBV, without compression |
Frequency Response | 80Hz to 40kHz, +/-1.0dB |
Noise | <-65dB (below -10dBV output, -50dBu input) |
Power Requirements | 24VDC via included power supply |
Dimensions | 5.75 x 3.0 x 1.7" (146 x 76 x 43mm) |
Weight | Not specified by manufacturer |
Specialties | Compressor limits clipping over a wide dynamic range |
