Product Description
RDL EZ-HDA4B 4-Channel Stereo Headphone Distribution Amplifier (Rear Outputs)
Overview
The EZ-HDA4B contains four stereo headphone amplifiers with individual front-panel volume controls. Headphone outputs are provided on rear-panel MINI jacks. One stereo input signal feeds all the amplifiers. Stereo RCA jacks, a MINI jack and a 1/4" jack are provided for connecting the input source. The EZ-HDA4B is used in music stores, houses of worship, studios, museums, home component systems and commercial sound systems.
Power Supply Included
- PS-24AS (USA)
- PS-24AX (International)
Features
- One Stereo Input to Four Stereo Outputs
- Unbalanced Inputs on Rear Panel
- Input on MINI, 1/4" (6.3 mm) or RCA Jacks
- Headphone Outputs on Rear Panel
- Outputs on MINI Jacks
- Front-Panel LEVEL Control for Each Output
Advantages
- Gold-Plated RCA Input Connectors
- Each Output is Driven Separately
- Knobs for Easy Level Adjustment
Specifications
Form Factor | Tabletop (Rack-Mountable with Included Hardware) |
Number of Headphone Channels | 4-Channel |
Display | None |
Connectivity
Analog Audio I/O | 4 x 1/8" / 3.5 mm TRS Stereo Output (Rear Panel) 1 x Stereo RCA Phono Input 1 x 1/4" TRS Stereo Input 1 x 1/8" / 3.5 mm TRS Stereo Input |
Performance
Frequency Response | 20 Hz to 50 kHz ±1.5 dB |
THD+N | < 0.1% (10 mW, 100-Ohm Load) |
Noise | < -95 dB (100-Ohm Load, Max Gain) |
Physical
Dimensions | 5.75 x 3" / 14.6 x 7.6 cm |
