Product Description

Q5X QT-5100 AquaMic LL Micro Sized Transmitter

Overview

Micro sized transmitter, in an aluminum waterproof, submersible case. With an internal lithium polymer rechargeable battery and Lemo connector for a removable lavalier.

• Belt pack style
• 16 hr run time @ 50mW (AquaMic L)

Completely Submersible

The QT-5100® AquaMic™ is the waterproof version of the Award Winning QT-5100® series of transmitters. The QT-5100® AquaMic™ is completely waterproof, fully submersible.

Trial by Water

Used in reality TV, professional kiteboarding, surfing competitions and America’s Cup Yachting, the QT-5100® AquaMic™ has proven itself in extreme, wet environments.  The AquaMic is also buried in the dirt at various locations on the ball diamond as an effects mic for Major League Baseball.

QT-5100® Tech

The QT-5100® AquaMic ™ high quality broadcast audio transmitter has proven its worth exposed to the elements in some of the most demanding conditions.  The internal lithium battery lasts 8 to 16 hours on a single charge (depending on version and output power). With approximately 3,000 selectable frequencies in 3 blocks from 470 MHz to 700 MHz.  It features Q5X pre-emphasis DCS-QT companding and is comes standard with user selectable RF output power from 10mW to 100mW (regional restrictions apply).

Specifications

• Dimensions: 65mm x 46mm x 22.5mm (AquaMic L)
• Weight: 122.6g (AquaMic L)
• Housing Material: Machined Aluminum
• RF output power: 10mW to 100mW (user selectable, country restrictions apply)
• UHF frequency range 470 to 700 MHz in 3 frequency blocks
• Tunable bandwith: Varies by frequency block (25 kHz steps)
