Product Description
Q5X QR-M3 One-Channel, True Dual-Diversity, Mobile Receiver
Overview
One-channel, true dual-diversity, mobile receiver (ENG), in a commercial grade aluminum case, tunable to 9120 frequencies from 470MHz – 700MHz.
Specifications
- Dimensions: 112mm x 82mm x 24mm
- Weight: including battery, 291.4g
- Q5X companding – compatible with QT-5100 and Shure UHFR transmitters
- Mini XLR balanced output – Balanced: -18dBm (50mV)
- Headphone Jack (mini)
- SMA antenna connectors – comes with 2 Water resistant SMA antennas
- DC input connector – Barrel Connector (6 – 12vDC), micro USB, Hirose
- Battery charger – comes with 12V DC wall-wart charger
- Rechargeable lithium ion battery
- Available in frequency range of 470 MHz to 700 MHz
- Programmed in 25kHz steps
- OLED front and top display screens
- Frequency Stability – ±0.005%
- Sensitivity -100dBm at S/N ratio > 80dB
- Image rejection – > 80dB
- S/N Ratio – > 108dB
